Single-phase energy meter Asita 1 Din module EMS30C
ASI EMS30C
8032817464784
Single-phase energy meter Asita, with the following features:
- Direct current insertion up to 30A
- With accuracy class 1 as provided for by standard CEI EN 62053-21
- DIN rail installation
- It has a pulse output proportional to the energy detected to be combined with a distributed supervision system of the energy consumption of several single-phase electrical users powered at low voltage.
- Occupies only 1 DIN module
- 7-digit electromechanical indicator
- Operating temperature from -20˚C to +50˚C
- Measurement category CAT III-300V
- Protection degree IP20
- Power supply 230Vac ±20%.
- Dimensions 85x64x18 mm
- Weight 100 gr
Single-phase energy meter Asita 1 Din module EMS30C
€46.73
€46.73
Tax included
Tax included
Pay in installments with Klarna
Items Available: 1
Features:
- Asita Series
- Direct insertion of current up to 30A
- With accuracy class 1 as required by standard CEI EN 62053-21
- DIN rail installation
- It has a pulse output proportional to the energy detected to be combined with a distributed supervision system of energy consumption of several single-phase electrical users supplied with low voltage
- Occupies only 1 DIN module
- 7-digit electromechanical indicator
- Operating temperature from -20˚C to +50˚C
- Measurement category CAT III-300V
- Protection degree IP20
- Power supply 230Vac ±20%.
- Dimensions 85x64x18 mm
- Weight 100 gr
There are no reviews
Data sheet
- Type:
- Electricity meters
- Voltage:
- 230VAC
- Amps:
- 30A
