Abb MS132 motor circuit breaker 80-12A 3P 100kA, 2.5M DIN EP 981 5

Abb
Abb
ABB EP 981 5 4013614400124

Abb MS132 80-12A motor protection, efficient protection for motors up to 5.5 kW, with breaking power up to 100kA and precise regulation, with the following features:

  • Adjustment range: 8 - 12 A

  • Interrupting power: 100 kA at 230 V

  • Compatible with motors: up to 5.5 kW at 400 V (AC-3)

  • Status indication: ON / OFF / TRIP

  • Mounting: DIN rail 2.5 modules (45 mm)

  • Overload and short-circuit protection

Do you have questions about this product or did you not find what you were looking for? Ask us!
Abb MS132 motor circuit breaker 80-12A 3P 100kA, 2.5M DIN EP 981 5
€74.35
€74.35

€74.35
Tax included
Calculate shipping cost
Items Available: 6
Further availability of the manufacturer
€74.35

Buy it within and receive it from Wednesday, 21 January
Two-year warranty
Easy return within 14 days
Purchase with tax breaks

Are you a professional ?

Request access to

Trustpilot

Abb motor saver maximum protection for your motor

The Abb motor saver is a compact and reliable circuit breaker designed to protect three-phase electric motors from overloads, short circuits and phase failure. The device cuts off the power supply promptly in the event of excessive absorption, ensuring the safety of the motor and the system.

Performance and Safety Abb

Equipped with an interrupting power of 100 kA, the MS132 provides effective protection even under extreme fault conditions. Precise adjustment between 8 and 12 A allows it to adapt to a wide range of electric motors. The product complies with international IEC/EN standards and is suitable for industrial and civil environments.

Simple and versatile installation

Thanks to the front rotary knob, DIN rail mounting and compactness (only 2.5 modules), installation of the motor saver is quick and easy even in small spaces. Screw terminals accept various types of wiring.

Recommended applications

  • Three-phase motor protection up to 5.5 kW

  • Industrial plants with dynamic loads

  • Automation and electrical distribution boards

  • Protection against short circuits and phase failure

Technical Specifications Abb motor protection

Adjustable current 8 - 12 A
Supported motor power (400V AC-3) 5.5 kW
Rated current (Ie) 12 A
Rated voltage (AC/DC) 690 V AC / 250 V DC
Breaking capacity 100 kA @ 230 V
Actuator type Rotary knob
Poles 3
DIN modules 2,5
Mounting DIN rail
Degree of protection IP20 (housing), IP10 (terminals)
Electrical service life 50,000 cycles
Mechanical durability 100,000 cycles
Operating temperature -25 °C TO +70 °C
Insulation voltage (Ui) 690 V
Impulse withstand voltage (Uimp) 6 kV
Dimensions (W x H x D) 45 x 97.8 x 86.55 mm

There are no reviews

Data sheet

Type:
Motor protection
Modules:
2.5
Poles:
3P
Breaking capacity:
100KA
Amps:
8.0-12A
