FTE Mast amplifier 5G 3 Inputs BIII/UHF/UHF G30DB AMP313-5G
FTE AMP313-5G
8055271136554
The mast amplifier FTE AMP313-5G with 3 inputs BIII/UHF/UHF amplifies DTT signals in separate bands with 30 dB and output up to 114 dBµV, including 5G filter and rainproof housing.
-
Type: DTT mast amplifier
-
Inputs: 3 (BIII / UHF / UHF)
-
Amplification: separate bands BIII/UHF
-
Gain: 30 dB
-
Gain adjustment: 20 dB
-
Maximum output level: 114 dBµV
-
Filter: integrated 5G (latest generation)
-
Connectors: Type F
-
Shielding: shielded metal frame
-
Power supply: 12 Vdc / 80 mA
-
Remote power: 12 Vdc / 80 mA on UHF input
-
Installation: rainproof case + pole mounting strap
€27.87
Items Available: 1
Mast amplifier FTE AMP313-5G: stable and clean DTT signal
The FTE AMP313-5G is a mast amplifier designed to improve the quality of digital terrestrial television (DTT) signal in installations where the incoming level is insufficient or unstable. Thanks to the 3-input configuration (BIII/UHF/UHF) and separate band amplification, it allows for more precise signal management, reducing the risk of saturation and contributing to a more reliable distribution towards the home system or a small condominium network.
Separate BIII and UHF bands: more control, less interference
The separation of bands (BIII and UHF) is a tangible advantage when receiving different multiplexes or when using a combined BIII+UHF antenna oriented towards a repeater transmitting on both bands. The amplifier works by optimizing amplification for each section, improving system linearity and maintaining more stable performance even in the presence of signals with different levels.
Integrated 5G filter: modern protection for TV systems
With the expansion of LTE/5G networks, interference on the UHF band can become a frequent cause of pixelation and channel loss. The latest generation integrated 5G filter helps limit disturbances from mobile frequencies, making the AMP313-5G a suitable choice for new installations or upgrades of existing systems in areas where 4G/5G coverage is intense.
High performance and gain adjustment for small systems
With 30 dB gain and a maximum output level of 114 dBµV, this amplifier is suitable for signal distribution in small systems, where it is necessary to compensate for cable and branch losses without compromising quality. The gain adjustment up to 20 dB allows for finer tuning based on the actual level of the received signal, avoiding excesses that could create distortion or saturation downstream.
Outdoor installation: shielding, F connectors and rain protection
Designed for pole mounting, the AMP313-5G features a fully shielded metal frame and F-type connectors, ideal for reliable connections with coaxial cable and less sensitivity to interference. The rainproof plastic enclosure and pole mounting strap make installation more practical and protected over time.
Recommended applications
This amplifier is suitable for amplifying DTT signals from a single logarithmic or combined BIII+UHF antenna, oriented on a repeater with transmissions in BIII and UHF. It is an effective choice for homes, small systems, and limited distributions, with the possibility of remote power supply via coaxial cable using a 12 V power supply (e.g., LPS301 / LPS302 / LPS202).
| Technical data | |
|---|---|
| No. of inputs | 3 - BIII / UHF / UHF |
| Bands | 174 ÷ 230 MHz / 470 ÷ 694 MHz / 470 ÷ 694 MHz |
| No. of outputs | 1 |
| Gain | 30 / 30 / 30 dB |
| Gain adjustment | 20 / 20 / 20 dB |
| Max. output level VHF / UHF | 114 dBµV |
| Noise figure | BIII: <5 dB / UHF: <7 dB |
| Power supply voltage | 12 VDC |
| Consumption | 75 mA |
| Remote power supply on UHF input | 12 VDC / 80 mA |
| Maximum pole mount diameter | 60 mm (with PE strap) |
| Amplification type | LOG / UHF with separate bands |
| Frame type | Zamak alloy with metal covers |
| Enclosure type | UV shockproof PS |
| Operating temperature | -10 ÷ 50 °C |
| Dimensions (W x H x D) | 98 x 65 x 18 mm |
| Weight | 210 g |
| Single / multiple packaging quantity | 1 / 10 |
| Compliance standards | EN 50083-2; EN 60065; EN 55032; EN 55035; EN 61000-3-2; EN 61000-3-3; EMC Directive 2014/30/EU; EN 62368-1; LVD Directive 2014/35/EU; RED Compliant |
There are no reviews
Data sheet
- Type: Amplifiers
- Version: 3IN/1OUT
- Model: Pole
