Fracarro 4-way shunt 14dB CD2-14 220854

FRA 220854 8016978075140

Terminal shunt CD2-14 Fracarro Tv-Sat, 4-way.

Request info about this product

Fracarro 4-way shunt 14dB CD2-14 220854


Fracarro 4-way shunt 14dB CD2-14 220854

Tax included
klarna Pay in installments with Klarna

Fracarro 4-way shunt 14dB CD2-14 220854


Buy it within and receive it from Thursday, 20 June
Two-year warranty
Secure Payment
Easy return within 14 days

The new CAD S Fracarro family, thanks to its patented features of reliability and convenience, is the perfect complement to the Fracarro range of splitters and shunts.

The innovative cable clamping system allows perfect class A shielding and optimum impedance matching, and is the result of an accurate development project. They are, moreover. the only broadband clamped to allow single-cable connection.


  • Fracarro Series
  • Class A shielding
  • Bandwidth: 5-2400 MHz
  • Shunt loss: 14 dB
  • Insertion loss: 3.5-4.5 dB
  • Output separation: 33-25 dB
  • 1 input - 1 output - 4 leads
  • Quick and easy installation
  • High return loss
  • Very high isolation between outputs
  • Immune to external disturbances
  • High return loss
  • Grounding screw

Data sheet

4 outputs
