BM lugs for uninsulated aluminum conductors DIN 185-12 76185
BMM 76185
BM cable lugs for non-insulated aluminum conductors DIN 185-12 with the following characteristics:
- Non-compact circular or sectional conductor cross-section: 185 mm²
- Circular compact conductor cross-section: 240 mm²
- Screw diameter: 12 mm
- Stud size for screw: 1/2"
- Matrix hexagon number 28mm
- Material: aluminum 1050 A EN573-3 with purity not less than 99.5%
Conductor housing is filled with grease (drop point at 90°C) and closed with plastic cap to prevent oxidation.
€10.14
Items Available: 34
: 31
There are no reviews
Data sheet
- Diameter: 12mm
- Type: Terminal lugs
