Camera:

• 5 MP CMOS Image Sensor
• PAL/NTSC Signal System
• Resolution 2560(H) × 1944(V)
• Frame Rate TVI: 5 M at 20 fps, 4 M at 30 fps, 4 M at 25 fps, 1080p at 30 fps, 1080p at 25 fps - AHD: 5 M at 20 fps, 4 M at 30 fps, 4 M at 25 fps - CVI: 4 M at 30 fps, 4 M at 25 fps - CVBS: PAL/NTSC
• Min. Illumination 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR
• Release Time PAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s
• Lens Motorized varifocal lens from 2.7 mm to 13.5 mm
• Field of View Horizontal FOV: 95° to 26°, Vertical FOV: 72° to 20°, Diagonal FOV: 126° to 33°
• Lens Mount F14
• Day Night IR Cut Filter
• WDR (Wide Dynamic Range) Digital WDR
• Panoramic Angle Adjustment: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360°.



Image:

• Day/Night Auto/Color/BN (black and white) Mode.
• Image Mode STD/HIGH-SAT
• AGC Yes
• White Balance Auto/Manual
• AE (Auto Exposure) Mode BLC;HLC;Global;DWDR
• Noise Reduction DNR 2D
• English Language
• Sharpness Function;Brightness;Smart IR



Interface:

• TVI/AHD/CVI/CVBS Switchable Video Output



Features:

• IR Range Up to 40 m
• Operating Conditions -40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing)
• Power Supply 12 VDC±15%, 24 VAC±15%.
• Maximum Power Consumption 8.8 W
• Protection Level IP67
• Material Front Cover: metal, Main Body: plastic
• Communication HIKVISION-C
• Size 84.5 mm × 92 mm × 255.1 mm (3.33" × 3.62" × 10.04") approx. 682 g (1.50 lbs).
