Dahua IP Dual Light Varifocal Bullet Camera 4MP M-0035596
DAH M-0035596
6939554927102
Dahua varifocal motorized IP camera with dual IR/hot light up to 60 m. WizSense AI technology for advanced detection of people and vehicles, with the following features:
-
Sensor: 4 MP 1/2.9" CMOS, high-definition image even in low light
-
Resolution: 4 MP (2688×1520) at 25/30 fps
-
Lens: 2,713.5 mm motorized varifocal, 104°29° horizontal field of view
-
Illuminators: IR + hot light up to 60 m, intelligently activated
-
Intelligent video analysis: tripwire, intrusion, SMD 4.0, AI SSA, AcuPick
-
Microphone: Built-in and two-way audio support
-
Degree of protection: IP67
-
Power Supply: PoE/12V DC
-
MicroSD slot: Up to 512GB
-
Compatibility: ONVIF, management via SmartPSS, DSS, DMSS
-
Color: White
€207.40
Items Available: 10
: 1
Frequently bought together
Dahua IPC-HFW3449T-ZS-IL camera: maximum intelligence for security
The IPC-HFW3449T-ZS-IL is a 4 MP resolution outdoor Bullet network camera designed for installations requiring high image quality, advanced video analytics and optical flexibility. With WizSense technology, it ensures accurate detection of vehicles and people with reliable artificial intelligence even in harsh conditions.
Dual smart illumination: clear vision day and night
Equipped with 4 multi-spectrum IR LEDs + warm light, it offers smart illumination up to 60 meters. Based on the environment, the illumination adjusts automatically ensuring sharp video even in total darkness, triggering alarms in a targeted manner on actual events.
Motorized varifocal lens: flexibility in every scenario
Motorized optics from 2.7 to 13.5 mm allow wide adjustment of the field of view, adapting to entrances, perimeters, parking lots or corridors. The DORI system ensures accuracy in detection and identification of subjects.
Video Intelligence with AI and Smart NVR
IVS and SMD 4.0 functions enable automatic classification of people and vehicles, reducing false alarms. With AcuPick system support and smart search, specific events can be quickly found among hours of recordings.
Reliability and connectivity for every context
IP67 metal housing for outdoor use in all conditions, PoE or 12VDC power supply for versatile installations, 3 video streams, built-in microphone, up to 512 GB of local storage, and advanced network protocols for total compatibility.
Ideal applications
-
Residential and enterprise perimeter security
-
Monitoring of parking lots, entrances, warehouses
-
Installations in hostile or low-light environments
-
Integrated systems with intelligent NVRs and Dahua platforms
Technical Specifications Dahua Bullet Camera
General Information
| Parameter | Value |
|---|---|
| Sensor | 1/2.9" CMOS |
| Maximum resolution | 2688 × 1520 |
| RAM / ROM | 1 GB / 256 MB |
| Minimum illumination | 0.005 lux (color), 0.0005 lux (B/W), 0 lux (IR on) |
| Illumination distance | Up to 60 m (IR + warm light) |
| Illuminators | 4 multi-core (IR + warm) |
| Degree of protection | IP67 |
| Casing material | Metal |
| Dimensions | 238.5 × 90.7 × 90.7 mm |
Optics and Performance
| Parameter | Value |
|---|---|
| Lens | Motorized vari-focal 2.7-13.5 mm |
| Aperture | F1.4 |
| Field of view | Horizontal: 104°-29°, Vertical: 54°-16°, Diagonal: 125°-34° |
| Minimum focusing distance | 0,1 m |
| Angle adjustment | Pan: 0°-360°, Tilt: 0°-90°, Rotation: 0°-360° |
DORI - Operating Distances
| Zoom | Detection | Observation | Recognition | Identification |
|---|---|---|---|---|
| Wide | 64 m | 25,6 m | 12,8 m | 6,4 m |
| Tele | 210 m | 84 m | 42 m | 21 m |
Smart Functions
| Parameter | Value |
|---|---|
| IVS | Tripwire, Intrusion with vehicle and person detection and classification |
| SMD | Version 4.0 |
| AcuPick | Intelligent target search (AI + back-end) |
| AI SSA | AI-based automatic image adaptation |
| Smart Search | Supported via Smart NVR |
Video
| Parameter | Value |
|---|---|
| Compression | H.265, H.264, MJPEG |
| AI encoding | AI H.265, AI H.264 |
| Frame rate | Up to 30 fps @ 2688x1520 (primary stream) |
| Streaming | 3 simultaneous streams |
| WDR | 120 dB |
| Image functions | 3D NR, BLC, HLC, SSA, RoI, privacy masking (8 areas) |
| Rotation | 0°/90°/180°/270° |
Audio
| Parameter | Value |
|---|---|
| Built-in microphone | Yes |
| Compressions supported | G.711a, G.711Mu, PCM, G.726, G.723 |
Alarm System
| Parameter | Value |
|---|---|
| Events Supported | Motion, Intrusion, Tripwire, Audio, Blur, Scene changes, SMD, SD errors, Disconnections, etc. |
| Alarm Relay | 3 NO/NC relays (1A - 30V DC) |
Network
| Parameter | Value |
|---|---|
| Network port | RJ-45 10/100 Base-T |
| Protocols | IPv4/IPv6, HTTP, HTTPS, TCP, UDP, RTSP, P2P, NTP, ONVIF, etc. |
| Users | Up to 20 (64 Mbps total) |
| Storage | Micro SD (max 512 GB), NAS, FTP/SFTP |
| Security | Encryption, WSSE, X.509, HTTPS, 802.1x |
Power and Power Consumption
| Parameter | Value |
|---|---|
| Power | 12 VDC / PoE (802.3af) |
| Power Consumption (typical) | 3.2 W (DC) / 4.8 W (PoE) |
| Power consumption (max) | 9.3 W (DC) / 11.9 W (PoE) |
Environment
| Parameter | Value |
|---|---|
| Operating temperature | -30 °C TO +60 °C |
| Operating humidity | ≤95% (without condensation) |
| Storage temperature | -40 °C ÷ +60 °C |
| Storage humidity | ≤95% (non-condensing) |
Certifications
| Parameter | Value |
|---|---|
| Certifications | CE-LVD: EN62368-1, CE-EMC: EMC Directive 2014/30/EU |
There are no reviews
Data sheet
- Type: Bullet cameras
- Degree of protection: IP67
- System: IP
- Optical: 2,7-13,5 mm
- Resolution: 4MP (2K)
