Dahua WizSense Bullet Camera 5MP 1/2.7" M-0033582
DAH M-0033582
6923172525543
Dahua WizSense IPC-HFW3549T1-AS-PV-S5 (M-0033582) is a 5MP bullet IP with active deterrence: dual smart light (IR + warm light 30 m), siren/red-blue lights, SMD 4.0 and AI analysis for people/vehicles for more accurate alarms.
-
5MP 1/2.7mm CMOS sensor with resolution up to 2960×1668 @ 20 fps
-
H.265 compression + Smart codec (Smart H.264+/H.265+, AI H.264/H.265) for less bandwidth and storage
-
Dual illumination: IR 30 m + warm light 30 m (dual smart light)
-
WizSense analysis: intrusion and tripwire with people/vehicle classification, + SMD 4.0
-
Active deterrence: sound and light alarm with red and blue lights
-
Advanced audio: dual microphone + speaker, two-way conversation; microSD up to 512 GB not included.
€236.81
Items Available: 8
: 3
Frequently bought together
Bullet WizSense 5MP with active deterrence: more effective security, fewer false alarms
The Dahua IPC-HFW3549T1-AS-PV-S5 is a network camera from the WizSense line designed for those who want to move from simple recording to active prevention. In addition to 5MP video quality, it integrates intelligent functions that more accurately distinguish people and vehicles, reducing false alarms typical of rain, insects, shadows, or vegetation. In residential and business contexts such as entrances, gates, courtyards, parking lots, perimeters, this means more reliable notifications and quicker interventions.
5MP video and complete image management: WDR, 3D NR, and scene optimizations
The 1/2.7" sensor with a maximum output of 5MP (2960×1668) at 20 fps offers a good level of detail for identifying subjects and dynamics in the scene. To tackle the most challenging conditions, the camera includes processing functions such as WDR, 3D NR, HLC, and BLC, as well as rotation modes and digital watermarking. The result is a more readable image in the presence of backlight, headlights, reflections, and noise at night.
Dual smart light: IR + warm light up to 30 metres
One of the strengths of the PV series is the dual smart light: the camera can rely on both IR LEDs and warm light, both with a range of up to 30 m. This allows you to choose the best approach: discreet infrared vision or colour illumination more useful for recognizing details (clothing, colours, features). Additionally, the SMD area can be set in zones illuminated by warm light, improving event management and alarm effectiveness.
WizSense intelligence: tripwire, intrusion, loitering, and SMD 4.0
The camera supports intelligent monitoring functions such as intrusion and tripwire, with accurate classification and detection of vehicles and people. Loitering and parking detections are also available, as well as full image face detection (useful for searches and verifications, depending on the management system). SMD 4.0 technology further enhances motion analysis, helping to filter out irrelevant events and focus on those that really matter.
Active deterrence: red/blue lights and sound alarm
When prevention is needed, seeing is not enough: it is also necessary to make it clear that the area is protected. This Dahua integrates sound and light alarms with red and blue lights, configurable to activate upon the occurrence of events (e.g., nighttime intrusion). It is a very effective function to discourage unauthorized access before it becomes a real problem.
Audio and I/O: two-way communication and system integration
The audio equipment is complete: dual integrated microphone for clearer capture and speaker for sending messages or alerts, with support for two-way conversation. There are also 1 alarm input and 1 alarm output, as well as 1 audio input and 1 audio output for integration with external devices. Local recording is supported via microSD up to 512 GB, useful as a backup or for installations without NVR.
Outdoor installation: IP67 and PoE power supply
For outdoor installation, IP67 protection ensures resistance to dust and water. Power can be supplied via 12 VDC or PoE, allowing you to simplify cabling by carrying power and data with a single Ethernet cable, ideal for professional installations.
| BASIC INFORMATION | |
|---|---|
| Brand / Series | Dahua WizSense – series 3549-PV-S5 |
| Model | IPC-HFW3549T1-AS-PV-S5 |
| Code | M-0033582 |
| Type | Bullet network camera with fixed focal length and active deterrence |
| SENSOR AND VIDEO | |
| Sensor | CMOS 5 MP 1/2.7" |
| Resolution / FPS | Max 2960 × 1668 @ 20 fps |
| Codec | H.265, Smart H.264+ / H.265+, AI H.264 / H.265, ROI |
| Image functions | Rotation, WDR, 3D NR, HLC, BLC, digital watermark |
| ILLUMINATION | |
| IR illumination | Up to 30 m |
| Warm light illumination | Up to 30 m |
| AI AND VIDEO ANALYTICS | |
| AI functions | Intrusion, Tripwire (people/vehicles), loitering, parking, face detection |
| Advanced functions | SMD 4.0, AI SSA, activation/deactivation one-touch |
| Detected anomalies | Motion, privacy mask, scene change, audio detection, SD absent/full/error, network, IP conflict, illegal access, voltage detection |
| I/O AND AUDIO | |
| Alarm I/O | 1 input / 1 output |
| Audio I/O | 1 input / 1 output |
| Audio | Dual microphone + speaker, two-way talk |
| STORAGE | |
| Memory slot | MicroSD up to 512 GB not included |
| POWER AND PROTECTION | |
| Power supply | 12 VDC / PoE |
| Protection | IP67 |
| Deterrence | Sound and light alarm (red and blue lights) |
There are no reviews
Data sheet
- Type: Bullet cameras
- Degree of protection: IP67
- System: IP
- Optical: 1-2.7mm
- Resolution: 5MP
