SMD Plus:

• With an intelligent algorithm, Smart Motion Detection technology can classify the targets that trigger motion detection and filter the motion detection alarm triggered by unaffected targets to realize an effective and accurate alarm.



Intelligent H.265+ and Intelligent H.264+:

• With advanced scene-adaptive rate control algorithm, intelligent encoding technology realizes higher encoding efficiency than H.265 and H.264, provides high-quality video and reduces storage and transmission costs.




Perimeter protection:

• Using deep learning algorithm, the perimeter protection technology can accurately recognize people and vehicles. In restricted area (e.g., such as pedestrian area and vehicular area), the false alarms of intelligent detection based on target type (such as tripwire, intrusion, fast movement, parking detection, parking detection, and assembly detection) are largely reduced.



Starlight:

• With an intelligent algorithm, Smart Motion Detection technology can classify targets that trigger motion detection and filter the motion detection alarm triggered by unaffected targets to realize an effective and accurate alarm. Starlight technology is mainly applied to low-light environments and can provide clear and colorful video. Even in the min. lighting environment, the technology can provide a good image effect.



WDR:

• With advanced Wide Dynamic Range (WDR) technology, the network camera provides clear details in an environment with strong brightness contrast. The light area and dark area can achieve sharp video even in high brightness environment or with backlight shadows




Features:



Camera:

• 1/34 Megapixel progressive CMOS image sensor
• Maximum Resolution 2688(O)×1520(V)
• Rom 128MB
• RAM 512MB
• Progressive Scanning System
• Electronic Shutter Speed Auto/Manual 1/3 s1/100000 s
• Minimum Illumination 0.005 Lux@F1.5
• S/N ratio > 56dB
• Illumination distance 60 m (197 ft.)
• Illuminator on/off control Auto/manual
• Number of illuminator 4 (IR LEDs)
• Pan/tilt/rotation range Pan: 0°360°; Tilt: 0°90°; Rotation: 0°360°



Lens:

• Lens type Fixed focal length
• Mounting type M12
• Focal length 3.6mm
• Maximum Aperture F1.6
• Field of view 3.6 mm: Horizontal: 84°; vertical: 45°; diagonal: 100°
• Fixed iris type



Professional, Smart:

• Tripwire perimeter protection; intrusion (person and vehicle recognition)
• Smart Search Collaborates with Smart NVR to refine smart search, event extraction and merging to event video



Video:

• H.265 video compression; H.264; H.264H; H.264B; MJPEG (supported by secondary stream only)
• Intelligent Intelligent H.265+/ Intelligent H.264+ codec
• Video frame rate: Main stream (2688 × 1520 at 125/30 fps) - secondary stream (704 × 576 at 125 fps/704 × 480 at 130 fps) - third stream (1280 × 720 at 125/30 fps)
• 3 stream capacity
• Resolution: 4M (2688×1520); 3M (2304×1296); 1080p (1920×1080); 1.3 million (1280 × 960); 720p (1280×720); D1 (704×576/704×480); VGA (640×480); CIF (352×288/352×240)
• CBR/VBR bit rate control
• Video bitrate H.264: 3 Kbps8192 Kbps H.265: 3 Kbps8192 Kbps
• Day Night Auto(ICR)/Color/B&W
• BLC
• HLC
• WDR 120dB
• White balance Auto/natural/roadlight/outdoor/manual/custom regional
• Get control Auto/manual
• 3D DNR Noise Reduction
• Motion detection OFF/ON (4 areas, rectangular)
• Region of Interest (RoI) Yes (4 areas)
• Intelligent illumination
• Image rotation 0°/90°/180°/270° (Supports 90°/270° with resolution 1920 × 1080 and lower
• Privacy masking 4 areas



Alarm:

• Alarm event No SD card; SD card full; SD card error; less SD card service time (supports smart card); network disconnection; IP conflict; illegal access; voltage detection; security exception; motion detection; scene change; intensity change; tripwire; intrusion; SMD



Network:

• RJ-45 (10/100 Base T)
• SDK and API
• Protocol Pv4;IPv6;HTTP;HTTPS;TCP;UDP;ARP;RTP;RTSP;RTCP; RTMP;SMTP;FTP;SFTP;DHCP;DNS;DDNS;QoS;UPnP;NTP; Multicast;ICMP;IGMP;NFS;PPPoE;802.1x;SNMP
• FTP; SFTP; Micro SD card (supports max. 256 GB); Dahua Cloud; NAS



Certifications:

• CE-LVD Certifications: EN62368-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part 15, Subpart B



General:

• 12V DC/PoE (802.3af) Power Supply.
• Power consumption <5.4 W
• Operating conditions -40°C to +60°C (-40°F to +140°F)/less than 95%.
• Storage conditions -40°C to +60°C (-40°F to +140°F)
• IP67 degree of protection
• Metal casing
• Dimensions 192.7 mm × 70.5 mm × 66.4 mm (632.2" × 231.3" × 217.8") (L × W × H)
• Net weight 590 g (1.3 lb)
