Lazzarini Sanremo straight electric radiator 803x500x450mm white 100982
LZZ 100982
8051406343217
Lazzarini Sanremo straight radiator 803x500 mm white, 17 steel tubes. Compact, elegant and electrifiable. Perfect for heating small and medium-sized bathrooms.
-
Dimensions: 803 x 500 mm, center distance 450 mm
-
17 horizontal tubes Ø22x0.9 mm
-
D-profile manifolds 40x30x1.2 mm
-
Carbon steel, white RAL 9016 finish
-
Compatible with single-pipe valve, flag connection, combined use
-
Electrifiable with immersion heater (not included)
€44.64
Items Available: 2
: 1
Lazzarini Sanremo straight electric radiator: Compact design and clean style for every bathroom
The Lazzarini Sanremo straight 803x500 mm electric radiator is ideal for small bathrooms or as an additional towel warmer in larger rooms. With its linear design and white shiny RAL 9016 finish, it blends harmoniously into any decor, offering functionality and style.
Quality materials and sturdy construction
Made of carbon steel, this model consists of 17 horizontal tubes with a diameter of 22 mm and a thickness of 0.9 mm, connected to two D-profile side manifolds (40x30x1.2 mm). The structure provides good heat transmission, ensuring effective heating of the room and quick drying of towels.
Easy wall mounting and standard connections
The radiator comes with 3 shelf brackets for wall mounting, included in the scope of supply, and has 3x1/2" connections, including the connection for the vent valve. The 450 mm spacing makes it easy to install as a replacement for other models without structural changes.
Prepared for electrification and combined use
The San Remo 803x500 can be converted into an electric radiator thanks to the provision for installation of an immersion electric heater (not included).
| Feature | Value |
|---|---|
| Model | Lazzarini Sanremo straight |
| Product code | 100982 |
| Height | 803 mm |
| Width | 500 mm |
| Wheelbase | 450 mm |
| Horizontal tubes | 17 tubes Ø22 × 0.9 mm |
| Manifolds | D profile 40×30×1.2 mm |
| Material | Carbon steel |
| Finish | White RAL 9016 |
| Connections | 3 × 1/2" (vent valve included) |
| Wall mounting | 3 oval brackets included |
| Compatibility | Single-pipe valve, flag connection, combined use |
| Electrifiable | Yes (resistor not included) |
| Max operating pressure | 10 bar |
| Max operating temperature | 90 °C |
| Painting | Epoxy-polyester powder |
| Packaging | P.P. corners + cardboard box + outer nylon |
| Standard equipment | 1 wall fastener kit - 1 vent valve |
| Weight | 5.7 kg |
| Water capacity | 3.9 liters |
| Power at ΔT 50°C | 420 W |
| Power at ΔT 30°C | 225 W |
| Power at ΔT 42.5°C | 345 W |
| Power at ΔT 60°C | 526 W |
| Electrical resistance | 500 W |
| Exponent n | 1,22603 |
There are no reviews
Data sheet
- Colour: White
- Type: Electric radiators
- Installation: Vertical
- height: 803mm
- Series: San Remo
- Axle base: 450mm
- Width: 500mm
