DC INPUT

• Maximum DC power 9000W
• Maximum DC voltage 600V
• MPPT voltage range 70 - 550V
• Nominal DC Voltage 360V
• Minimum DC Voltage 70V
• Start Voltage 90V
• Maximum DC input current 14 / 14 A
• Maximum Short Circuit Current 16 / 16 A
• Number of DC inputs for each MPPT 1 / 1
• Number of MPPT 2
• Integrated DC disconnector (DC-PV2).

Battery parameters

• Lithium battery (LiFePO4)
• Input voltage range 80 - 480 V
• Max. charge / discharge current 30 / 30 A.

Measurement of electrical parameters:

• Measuring device (delivery included) No. 1 TA current transformer for currents up to 100 A, as a replacement for the meter
• Functionality Measurement of electrical parameters of withdrawal and input, necessary for the management of external loads and charging/discharging of the storage system
• CT - inverter connection cable 0.5 m connection cable (included). For longer lengths (maximum 100 m) use CAT5 data cable (supply not included). RJ45 plugs (included), RJ45 junction for data cable extension (included).

AC OUTPUT:

• Nominal power 6000 VA
• Maximum power 6600 VA
• Nominal current 26.1 A
• Maximum current 28.6 A
• Mains voltage / Range 220, 230, 240 V / 180 - 270 V
• Mains frequency 50, 60 Hz
• Power factor
• cos ? 0.8 capacitive - 0.8 inductive
• THDi, nominal power < 2
• Connection Single-phase 1L + N + PE.

AC OUTPUT (BACK-UP MODE)

• Maximum AC power 6000 VA
• Maximum peak power 7200 VA, 10 min
• Nominal voltage 230V
• Frequency 50, 60 Hz
• Switching time Internal < 10ms , external < 100ms
• THDv, linear load < 2
• Connection Single-phase 1L + N + PE.

Protections

• AC and DC over- or undervoltage protection
• Reverse current monitoring
• Islanding protection
• Overload protection
• Overtemperature protection
• Battery reverse polarity protection.

General data:

• Transformerless topology
• Standby consumption < 3 W
• Operating temperature range -35°C to +60°C (derating from +45°C)
• Cooling method Natural convection
• Ambient humidity 0 to 100 % non-condensing
• Storage temperature range -40°C to +70°C
• Altitude Up to 3000 m
• Noise < 30 dB
• Degree of protection IP65
• Mounting Wall mounting bracket
• Dimensions (H x W x D) 482 x 417 x 181 mm
• Net Weight 22Kg.

Interface

• AC connection Terminal block
• Photovoltaic input MC4
• Back-up line connection Terminal block
• Battery Connectors
• LCD screen
• Communication modes (monitoring system) Wi-Fi (PSI-X-H-WIFI module included) / LAN (PSI-X-H-ETH module optional)
• Communication ports (internal and with battery) Dongle (USB port for Wi-Fi/Ethernet module) / BMS (RJ45 port for battery communication) / Meter / CT (RJ45 port for meter communication) / CAN (RJ45 port for parallel function) / COM / LCD (RJ45 port for external communication).
