Advantages:

• Integrated DC & AC Surge Arresters
• 110% AC Overload
• Maximum efficiency 98.8%




Input (DC):

• Maximum field power 75000W
• Maximum input voltage 1100V
• MPPT voltage range 180-1000
• Nominal input voltage 600V
• Start-up voltage 200V
• Max input current 32/32/32/32/32A
• Maximum short circuit current 38.4/38.4/38.4/38.4A
• Number of strings per MPPT 2/2/2/2
• Number of MPPTs 4



Output (AC):

• Rated AC output power 50000W
• Max AC output power 50000W
• Nominal AC output current 72.5A
• Max AC output current 75.8A
• Nominal AC voltage / range 3L+N+PE, 220/380, 230/400, 240/415; 180-280/312-485V
• Nominal AC mains frequency / range Hz 50, 60 / 44-55, 54-65
• Total harmonic distortion <3% THDi
• Power factor cos 0.8 capacitive ~0.8 inductive



Efficiency:

• Maximum efficiency 98.8%
• European efficiency 98.5%



Protections:

• Integrated DCI monitoring
• Integrated GFCI monitoring
• Integrated network monitoring
• AC grounding detection lntegrated
• AC-side short circuit protection lntegrated
• DC insulation resistance detection lntegrated
• DC overvoltage protection Type II
• AC overvoltage protection Type Ill
• AFD anti-islanding protection
• AFCI protection Optional not integrated



Interface:

• AC Connections Terminal Block
• MC4 DC Connections
• LED screen+APP (Bluetooth)
• RS232+RS485 (RJ45)+DRM(RJ45) communication port
• Wi-Fi/Ethernet/4G communication mode
• 24/7 load monitoring (Optional not integrated)



General Data:

• Transformerless topology
• Nighttime consumption W <0.6
• Operating temperature range -40°C~+60°C
• Cooling method Inteligent cooling by fan
• Ambient humidity 0%~100% without condensation
• Altitude 4000m (>3000m with power limitation)
• Noise
• dBA <50
• Degree of protection IP65
• Mounting Wall mounting bracket
• Dimensions (H*W*D) 473*659.4*240mm
• Weight 37.5kg



Certifications:

• IEC/EN62109-1/2, EN61000-6-1/2/3/4, IEC61683, IEC60068-2, IEC62116, IEC61727, PEA/MEA,VDE0126-1-1/A1, CEI 0-21, VDE-AR-N 4105, AS/NZS4777.2, CQC NB/T 32004, G98/G99, NBR 16149, NBR 16150, C10/11,RD1669,UNE206006, UNE206007,EN50438.
