Features:




Efficiency:

• Maximum 98.5%
• Efficiency European Efficiency 98.0%




Input:

• Maximum voltage 1100V
• Max Current for MPPT 30A
• Max Current for Inputs 20A
• Max Input Circuit Current 40A
• Max starting voltage 200V-1000V
• Number of inputs 8
• Number of MPPTs 4



Output:

• Rated AC active power 50,000W
• Apparent AC Power Max 55000V
• AC Active Power Max 55000W
• Rated Output Voltage 400 Vac / 480 Vac, 3W+(N) + PE 50
• Nominal AC grid frequency Hz / 60 Hz 72.2 A at 400 Vac
• Rated output current 72.2 A @ 400Vac, 60.1 A @ 480Vac
• Max output current 79.8 A @ 400Vac, 66.5 A @ 480Vac
• Adjustable power factor range 0.8 LG ... 0.8 LD
• Max. Total Harmonic Distortion 3 %




Protections:

• Input-side disconnect device
• Insulation monitoring
• DC overvoltage protection Yes, compatible with protection class TYPE II according to EN / IEC 61643-11
• AC overvoltage protection Yes, compatible with protection class TYPE II according to EN / IEC 61643-11
• String failure monitoring
• DC Surge Arrester Type II
• AC Overvoltage Surge Arrester Type II
• DC insulation resistance detection
• Residual current monitoring unit
• AFCI arc-fault protection
• Integrated PID recovery



Communications:

• LED Indicators display, Bluetooth + APP
• Built-in RS485
• WLAN/Ethernet via Smart Dongle-WLAN-FE (Optional to be purchased separately)
• 4G / 3G / 2G via Smart Dongle-4G (Optional to be purchased separately)
• Monitoring BUS (MBUS) (isolation transformer required)




Optimizer compatibility:

• DC MBUS compatible optimizer MERC-1100/1300W-P




General data:

• Dimensions (W x H x D) 530 x 270 mm (25.2 x 20.9 x 10.6 in.)
• Weight with mounting plate 49 kg
• Operating temperature range -25°C ~ 60°C (-13°F ~ 140°F)
• Max air cooling method
• Operating altitude Relative humidity 4,000 m (13,123 ft.)
• Relative humidity 0% RH ~ 100% RH
• DC connector Amphenol HH4
• AC connector Amphenol HH4 waterproof connector + OT/DT terminal
• IP66 degree of protection
• Transformerless topology
• Nighttime power consumption 5.5W
