Siemens Digital Output Module ET 200SP 8X 24V 6ES71316BF010BA0


SIE 6ES71316BF010BA0

Siemens SIMATIC ET 200SP digital input/output module with the following features:

  • Nominal value (DC) 24V
  • Permissible range, lower limit (DC): 19.2V
  • Permissible range, upper limit (DC): 28.8V
  • Reverse polarity protection: yes
  • Current consumption, max: 50 mA; all channels powered by transducer power supply
  • Number of outputs: 8
  • Output voltage, min:19,2V
  • Short circuit protection: yes, per module
  • Number of inputs: 8
  • Parameterizable digital inputs: yes
  • Reading on m/p: Reading on P
  • Input characteristic according to IEC 61131, Type 3: yes
Request info about this product

Siemens Digital Output Module ET 200SP 8X 24V 6ES71316BF010BA0

€61.08
€61.08

Siemens Digital Output Module ET 200SP 8X 24V 6ES71316BF010BA0

€61.08
Tax included
klarna Pay in installments with Klarna
qty

Siemens Digital Output Module ET 200SP 8X 24V 6ES71316BF010BA0

€61.08

Buy it within and receive it from Tuesday, 16 April
Two-year warranty
Secure Payment
Easy return within 14 days

Ambient temperature in operation:

  • Horizontal mounting position, min. -30 °C; < 0 °C from FS02
  • Horizontal mounting position, max. 60 °C
  • Vertical mounting position, min. -30 °C; < 0 °C from FS02
  • Vertical mounting position, max. 50 °C

Altitude during operation, with reference to sea level:

  • Max. installation altitude above sea level 5 000 m; Limitations for installation altitudes > 2 000m

Dimensions and weight:

  • Width 15 mm
  • Height 73 mm
  • Depth 58 mm
  • Weight: approx. 28 grams

Data sheet

Type:
Digital output modules
