Hikvision AXPRO Outdoor Detector DS-PDTT15AM-LM-WE Triple Technology 314300256
HIK 314300256
6931847146757
Hikvision AXPRO DS-PDTT15AM-LM-WE outdoor detector, triple technology:
- 90°@180° adjustable coverage
- IP65 weather resistance for outdoor applications
- Active IR anti-masking
- Multiple recording methods and easy installation
- Frequency hopping against jamming for reliable transmission
€205.57
Items Available: 25
: 2
Frequently bought together
Detection performance:
- Detection method Passive infrared: microwave
- Detection range 15 meters
- Detection angle 90° @ 180° adjustable
- Detection zones 92
- Detectable speed 0.3 ~ 2 m/s
- Sensitivity Automatic; Low
- White light filter 10000 lux
- Microwave frequency 24 GHz (24.15 ~ 24.25 GHz)
- Pet immunity 40 kg
- Digital temperature compensation
- Antimasking
- Adaptive coverage
- Pattern mask included
Features:
- Digital processing Three-signal logic
- Sealed Optics
- Anti-sabotage protection Front back
- Ambient temperature indicator
- Signal strength indicator
- Anti-oscillation analysis
Interface:
- Power switch Turn on recording
- LED indicator Green (upper PIR), red (microwave), orange (lower PIR), green + orange (mask), blue (alarm)
Transmission:
- Tri-X Wireless Transmission Technology
- Two-way Wireless RF Transmission Method
- Transmission Frequency 868 MHz
- Transmission Security AES-128 Encryption
- Transmission range (free space) 1.6 km
- Frequency hopping
- Enrollment method Power on; remote ID; QR code
Electrical characteristics:
- Standard battery life 5 years of work (Stand alone: activated 20 times a day) - (With integrated camera: is activated and fully charging acquisitions once a day)
- Power supply Charged battery
- Battery type CR123A × 5
- Typical voltage 3V
General information:
- Operating temperature -25 °C to 60 °C (-13 °F to 140 °F)
- Storage temperature -25 °C to 60 °C (-13 °F to 140 °F)
- Operating humidity 10% to 90%
- IP65 rate
- Dimensions (WxHxD) 75 mm × 202 mm × 73 mm
- Weight 600 grams
- Mounting height 0.8 to 1.2 meters
- Mounting method Wall
- Application Scenario Outdoor
There are no reviews
Data sheet
- Type: Detectors
- System: Triple Technology
- Installation: External
