Giacomini Boiler Straight Ball Valve F/F 3/4 R251PX014
GIM R251PX014
8009902333034
Giacomini boiler straight ball valve with red single-lever butterfly handle. Standard passage. For plumbing and meter connections, with the following features:
-
Connections: Female/Female 3/4 in.
-
Material: Nickel-plated brass
-
Handle: Red aluminum single-lever butterfly
-
Max working pressure: 16 bar at 20 degrees
-
Use: Under boiler and for meters
€8.99
Items Available: 15
: 3
Giacomini ball valve with cap for under-boiler installations
This straight ball valve with female/female threaded connections and G 3/4-inch cap is specifically designed for installation under boilers or for connection to water meters, in civil heating and cooling systems.
Solid nickel-plated brass construction
Made of brass, with nickel-plating surface treatment, the valve provides corrosion resistance and long service life, even in humid or frequently stressed environments.
Effective sealing and maneuverability
Lasta control with double O-rings ensures excellent sealing, while the single-finned butterfly handle, made of red-painted aluminum, enables quick opening and closing even in tight spaces. The nut features anti-corrosion coating, guarantee seal and authenticity hologram.
High performance in all conditions
With a temperature range of -20 +120 degrees, and a maximum operating pressure of 16 bar (1.6 MPa) at 20 degrees, this valve is also suitable for systems with up to 50 percent glycol solutions, ensuring all-weather reliability.
Technical Specifications Giacomini Ball Valve
Technical Data
| Feature | Value |
|---|---|
| Connections | G 3/4 female x cap G 3/4 female |
| Body material | Nickel-plated brass UNI EN 12165 CW617N |
| Handle | Red aluminum single-finned butterfly |
| Passage | Standard |
| Sealing system | Rod with double O-ring |
| Maximum operating pressure | 16 bar (1.6 MPa) at 20 °C (68 °F) |
| Temperature range | -20 °C to +120 °C (down to -20 °C with 50% glycol) |
Applications
| Fields of use | Description |
|---|---|
| Main Uses. | Plumbing systems, under boiler, meter connections, heating and cooling water |
There are no reviews
Data sheet
- Type: Ball valves
- Connection: F/F
- System: Water
- Connections: 3/4 inches
