Giacomini M/F 1/2 angle ball valve with handle R789X003

Giacomini
Giacomini
GIM R789X003 8009902168049

Giacomini angle ball valve with butterfly handle, full passage. For water, non-hazardous gases and liquid hydrocarbons, with the following features:

  • Connections: Male/Female 1/2 inch

  • Passage: Total

  • Material: Chrome-plated brass

  • Max water/gas pressure: 16 bar

  • Max liquid hydrocarbon pressure: 12 bar

Do you have questions about this product or did you not find what you were looking for? Ask us!
Giacomini M/F 1/2 angle ball valve with handle R789X003
€7.59
€7.59

€7.59
Tax included
Calculate shipping cost
Items Available: 1
Further availability of the manufacturer
€7.59

Buy it within and receive it from Wednesday, 11 February
Two-year warranty
Easy return within 14 days
Purchase with tax breaks

Are you a professional ?

Request access to

Trustpilot

Giacomini angle ball valve reliability, durability and versatility

The Giacomini angle ball valve is the ideal choice for applications in heating, cooling, and transporting liquid hydrocarbons and nonhazardous gases, providing continuous flow due to its full passage. The angled angle configuration is perfect for installations in confined spaces or on circuits that require flow detour.

Sturdy chrome-plated brass construction

Made of chrome-plated brass, the valve offers corrosion resistance and long life even in harsh environments. The butterfly handle, available in red or blue, allows quick and precise opening and closing action.

Perfect seal with double O-ring

Lasta control is equipped with double O-rings, which ensures excellent sealing even under high pressure conditions, limiting the need for maintenance and extending the valve's service life.

Wide range of use

The valve can be used with:

  • Water for heating/cooling systems

  • Glycol solutions up to 50 percent

  • Non-hazardous gases

  • Liquid hydrocarbons (with a maximum temperature of 60 °C)

Thanks to its compact design and versatility of use, it is perfect for civil, industrial and technical systems.

Technical Specifications Giacomini Ball Valve

Technical Data

FeatureValue
Connections M/F 1/2 inch with union
Passage Total
Body Material Chrome plated brass
Rod seal Double O-ring
Handle Painted aluminum butterfly


Operating Conditions

FluidMaximum temperature/pressure
Water -20 to 120 °C / 16 bar
Non-hazardous gases -20 to 120 °C / 16 bar
Liquid hydrocarbons -20 to 60 °C / 12 bar


Applications

Fields of useDescription
Suitability Heating and cooling
Domestic water
Non-hazardous gases
Liquid hydrocarbons

There are no reviews

Data sheet

Type:
Ball valves
Connection:
M/F
System:
Water
Connections:
1/2 inches
