Inverter for photovoltaic Riello Aros RS 6KW 2 MPPT Single Phase WIFI

Riello
Riello
RST 6PS16K0C 8032993010133

Riello Aros RS 6KW photovoltaic inverter:

  • Transformerless
  • Maximum efficiency 97.4%
  • European efficiency 97.1%
  • IP65 degree of protection for outdoor installation
  • Redundant control and protection devices
  • Wide MPPT range
  • Integrated dual-channel Wi-Fi
  • Convention cooling technology
  • LCD display + status LED
  • wifi
Do you have questions about this product or did you not find what you were looking for? Ask us!
Inverter for photovoltaic Riello Aros RS 6KW 2 MPPT Single Phase WIFI
€1,210.79
€1,210.79

€1,210.79
Tax included
Calculate shipping cost
Items Available: 4
Further availability of the manufacturer
€1,210.79

Buy it within and receive it from Monday, 22 December
Two-year warranty
Easy return within 14 days
Purchase with tax breaks

Are you a professional ?

Request access to

Trustpilot

Riello Elettronica strengthens its presence in the electrical conversion market with its new range of PV inverters totally dedicated to the residential sector under the Riello Solartech brand. Inverters in the RS range implement innovative technologies and high quality components, sized by a wide margin with respect to normal operating conditions and able to provide for periodic maintenance of the machines without sacrificing a wide flexibility of operation. Innovative digital control of all power stages ensures low sensitivity to mains disturbances, preventing unwanted disconnections in the presence of variations or micro interruptions. RS models integrate input and output surge protections and are equipped with redundant control and protection devices, particularly on the output stage, as a further guarantee of operability and continuity of operation.

Innovation:

  • Unique, innovative, lightweight and compact design. The die-cast aluminum case makes it particularly lightweight and provides a real IP65 degree of protection that is optimal even for outdoor applications. The materials chosen are of high quality to ensure maximum reliability. Thanks to the wide voltage range, the inverter can be perfectly integrated into different operating conditions of the power grid and is particularly suitable for low voltage typical in rural areas
  • Natural convection cooling technology to ensure a reliable period of use in high temperature situations
  • Intelligent self-testing with self-learning via App
  • Multiple remote monitoring for operation and maintenance.

Efficiency:

  • High efficiency and higher rate of return
  • Highest efficiency 97.6%
  • European efficiency 97.1%
  • MPPT self-learning technology to optimize the efficiency of each module
  • Wide MPPT range
  • Threshold voltage for delivery to the grid ultra-low.

Total flexibility:

  • Simple installation, smart operation and maintenance
  • User-friendly communication interface with built-in dual-channel Wi-Fi
  • Pluggable AC/DC connectors for instant connection
  • Use of App/Web for remote system control and firmware update, maintenance and smart operations.
  • Lightweight and extremely compact for easy installation.

Features:

EFFICIENCY:

  • Maximum efficiency 97.4%.
  • European efficiency 97.1%.

INPUT:

  • Maximum input voltage 600 V
  • Nominal input voltage 360 V
  • Maximum input current 26 A (13 A per MPPT)
  • Maximum short-circuit current 30 A (15 A for MPPT)
  • Starting voltage minimum operating voltage 90 V / 70 V
  • MPPT operating voltage range 90 V ÷ 580 V
  • Operating voltage range (full load) MPPT 300 V ÷ 520 V
  • Maximum number of PV strings 2 (1 / 1)
  • Number of MPPT 2

OUTPUT:

  • AC active power (nominal) 6000 W
  • Maximum apparent power AC 6600 VA
  • Maximum active power. AC (PF=1) 6600 W
  • Max AC output current 28.6 A
  • Nominal AC voltage AC 220 V / 230 V, L+N+PE
  • AC voltage range 160 V ÷ 300 V
  • Rated mains frequency 50 Hz / 60 Hz
  • Mains frequency range 45 Hz 55 Hz / 55 Hz 65 Hz
  • Harmonics distortion (THDI) < 3% (rated power)
  • DC current injection < 0.5% In
  • Power factor > 0.99 rated power

PROTECTIONS:

  • DC disconnect Si
  • Anti-island protection Yes
  • AC overcurrent protection Yes
  • Short-circuit protection Yes
  • DC pole reversal control Yes
  • AC surge arrester type III
  • Earth leakage detection Yes
  • Leakage current protection Yes.

GENERAL:

  • Type Transformerless
  • IP65 degree of protection
  • Self-consumption at night < 1 W
  • Natural Cooling
  • Operating temperature range -25 °C ÷ 60 °C
  • Relative humidity range 0 ÷ 100%
  • Maximum operating altitude 4000 m (> 2000 m derating)
  • Noise level < 30 dB (measured at 1 m)
  • Dimensions (WxDxH) 367 x 135 x 467 mm
  • Weight 12.9 kg.

COMMUNICATION:

  • LCD display + LED
  • Built-in Wi-Fi communication (dual channel), RS485 (optional)
  • APP monitoring, Supervisory portal

CERTIFICATIONS:

  • Safety IEC62109-I, IEC62109-2 EMC EN 61000-6-1, EN 61000-6-2, EN 61000-6-3, EN 61000-6-4
  • IEC 0-21, RD1699 Standards.
  • 5-year warranty.

There are no reviews

Data sheet

Type:
Inverter
Power:
6 to 10KW
WIFI:
Integrated
MPPT:
2
Connection:
Single-phase
