Other technical features:

• Riello series
• Transformerless
• Maximum efficiency 97,5%
• European efficiency 96,8%
• IP65 degree of protection for outdoor installation
• Redundant control and protection devices
• Wide MPPT range
• Integrated dual-channel Wi-Fi
• Convection cooling technology
• LCD display + status LED

INPUT:

• Maximum input voltage 600V
• Rated input voltage 360V
• Maximum input current 13A
• Maximum short-circuit current 15A
• Starting voltage - minimum operating voltage 90V / 70V
• MPPT operating voltage range 90V ÷ 580V
• Operating voltage range (full load) MPPT 240V to 520V
• Maximum number of PV strings: 1
• Number of MPPT: 1

OUTPUT:

• AC active power (rated) 3000W
• Maximum apparent AC power: 3300 VA
• Max. active power AC (PF=1): 3300 W
• Max. output current AC14.3A
• Nominal AC voltage: 220V / 230V, L+N+PE
• AC voltage range: 160V ÷ 300 V
• Rated mains frequency: 50 Hz / 60 Hz
• RetE frequency range: 45 Hz - 55 Hz / 55 Hz - 65 Hz
• Harmonics distortion (THDI): < 3% (rated power)
• DC injection: < 0.5% In
• Power factor: > 0.99 rated power

PROTECTIONS:

• DC disconnect switch Yes
• Islanding protection Yes
• AC overcurrent protection Yes
• Yes Short-circuit protection
• DC pole reversal protection Yes
• Type III AC Surge Arrester
• Earth leakage detection Yes
• Earth leakage current protection Yes

COMMUNICATION:

• Display: LCD + LED
• Communication: Built-in Wi-Fi (dual channel), RS485 (optional)
• Monitoring: APP, Supervision portal

CERTIFICATIONS:

• Safety IEC62109-I, IEC62109-2
• EMC EN 61000-6-1, EN 61000-6-2, EN 61000-6-3, EN 61000-6-4
• Standards CEI 0-21, RD1699
