Features:

DC INPUT:

• Maximum DC power 4500W
• Maximum DC voltage 600V
• MPPT voltage range 70 - 550V
• Nominal DC Voltage 360V
• Minimum DC Voltage 70V
• Startup Voltage 90V
• Maximum DC input current 14 / 14 A
• Maximum Short Circuit Current 16 / 16 A
• Number of DC inputs for each MPPT 1/1
• Number of MPPT 2
• DC disconnect switch (DC-PV2) integrated.

AC OUTPUT

• Rated power 3000 VA
• Maximum power 3300 VA
• Nominal Current 13.1 A
• Maximum current 14.4 A
• Mains voltage / Range 220, 230, 240 V / 180 - 270 V
• Mains frequency 50, 60 Hz
• Power factor
• cos > 0.8 capacitive - 0.8 inductive
• THDi, nominal power < 2
• Connection Single-phase 1L + N + PE.

AC OUTPUT (BACK-UP MODE)

• Maximum AC power 3000VA
• Maximum peak power 3600 VA, 1 hour
• Rated voltage 230V
• Frequency 50, 60 Hz
• Switching time Internal < 10ms , external < 100ms
• THDv, linear load < 2 %
• Connection Single-phase 1L + N + PE.

MEASUREMENT OF ELECTRICAL PARAMETERS

• Measuring device (supply included) No. 1 TA current transformer for currents up to 100 A, replacing the meter
• Functionality Measurement of electrical parameters of withdrawal and input, necessary for the management of external loads and the charge/discharge of the storage system
• CT - inverter connection cable 0.5 m connection cable (included)
• RJ45 plugs (included), RJ45 junction for data cable extension (included).

GENERAL DATA

• Topology Transformerless
• Standby consumption < 3 W
• Operating temperature range -35°C to +60°C (derating from +45°C)
• Cooling method Natural convection
• Ambient humidity From 0 to 100 % non-condensing
• Storage Temperature Range -40°C to +70°C
• Altitude Up to 3000 m
• Noise < 30 dB
• Degree of protection IP65
• Mounting Wall mounting bracket
• Dimensions (H x W x D) 482 x 417 x 181 mm
• Net weight 22 Kg.

INTERFACE

• AC connection Terminal block
• Photovoltaic input MC4
• Back-up line connection Battery terminal block Connectors
• LCD screen
• Communication mode (monitoring system) Wi-Fi (PSI-X-H-WIFI module included)
• Dongle (USB port for Wi-Fi/Ethernet module)
• BMS (RJ45 port for battery communication)
• Meter / CT (RJ45 port for meter communication)
• CAN (RJ45 port for parallel function)
• COM / LCD (RJ45 port for external communication).

PROTECTION:

• AC and DC over- or undervoltage protection Integrated
• Integrated reverse current monitoring
• Integrated anti-islanding protection
• Integrated overload protection
• Integrated overtemperature protection
• Integrated Battery Reverse Polarity Protection
