Advantages:

• Back-up function
• Practical and quiet
• Storage capacity of up to 46.0 kWh
• Including energy meter (TA)



DC INPUT:

• Maximum DC power 12000W
• Maximum power (MPPT1 / MPPT2) 7000 / 5000 W
• Maximum DC voltage 1000 V
• MPPT voltage range 180 - 950 V
• DC nominal voltage 640V
• Start-up voltage 200 V
• Maximum DC input current 26/16A
• Maximum short-circuit current 30/20A
• Number of DC inputs for each MPPT 2/1
• Number of MPPTs 2
• DC disconnect switch (DC-PV2) integrated



Battery parameters:

• Compatible storage devices (supply not included) Peimar PSI-X-PRL-BMS (Parallel BMS) - PSI-X-BT-5.8MST-HV (Master Battery) and Peimar PSI-X-BT-5.8SLV-HV (Slave Battery)
• Battery Type Lithium battery (LiFePO4)
• Input voltage range 180 - 650 V
• BMS / RS485 communication interface
• Max. charge/discharge current 30/30A



Possible battery configurations:

• 11.5 kWh = 1 Master PSI-X-BT-5.8MST-HV + 1 Slave PSI-X-BT-H5.8SLV-HV
• 17.5 kWh = 1 Master PSI-X-BT-5.8MST-HV + 2 Slaves PSI-X-BT-H5.8SLV-HV
• 23.0 kWh = 1 Master PSI-X-BT-5.8MST-HV + 3 Slaves PSI-X-BT-H5.8SLV-HV
• 11.5 kWh = 1 PSI-X-PRL-BMS + 2 PSI-X-BT-H5.8SLV-HV
• 17.3 kWh = 1 PSI-X-PRL-BMS + 3 PSI-X-BT-H5.8SLV-HV
• 23.0 kWh = 1 PSI-X-PRL-BMS + 4 PSI-X-BT-H5.8SLV-HV
• 23.0 kWh = 1 PSI-X-PRL-BMS + 2 PSI-X-BT-H5.8SLV-HV on port B1 + 2 PSI-X-BT-H5.8SLV-HV on port B2
• 34.6 kWh = 1 PSI-X-PRL-BMS + 3 PSI-X-BT-H5.8SLV-HV on port B1 + 3 PSI-X-BT-H5.8SLV-HV on port B2
• 46.1 kWh = 1 PSI-X-PRL-BMS + 4 PSI-X-BT-H5.8SLV-HV on port B1 + 4 PSI-X-BT-H5.8SLV-HV on port B2



AC OUTPUT:

• Rated power 8000W
• Maximum power 8800 VA
• Maximum output current 12.9 A
• Maximum input current 25.8A
• Rated line voltage 415 / 240 V; 400 / 230 V; 380 / 220 V
• Rated mains frequency 50, 60 Hz
• Power factor cos ? 0.8 capacitive - 0.8 inductive
• THDi, rated power < 3%
• 3-phase connection 3L + N + PE



AC OUTPUT (BACK-UP MODE):

• Maximum AC power 8000 W
• Maximum peak power 12000 VA, 60s
• Max. continuous current 11.6 A
• Rated voltage 400 / 230 V
• Rated frequency 50, 60 Hz
• Switching time <10ms
• THDv, linear load < 2%
• 3-phase connection 3L + N + PE



BUILT-IN PROTECTION:

• AC and DC over or under voltage protection
• Reverse current monitoring
• Anti-island protection
• Overload protection
• Over-temperature protection
• Battery reverse polarity protection



ELECTRICAL PARAMETER MEASUREMENT:

• Measuring device No. 3 TA current transformers included, for currents up to 100 A
• Functionality Measure electrical parameters of withdrawal and input, necessary for management of external loads and charging/discharging of the storage system
• TA - inverter connecting cable: 0.5 m connecting cable (included). For longer lengths (maximum 100 m) use CAT5 data cable or higher (supply not included). RJ45 plugs (included), RJ45 splice for data cable extension (included).



EFFICIENCY:

• Maximum efficiency 98.0%
• European efficiency 97.7%
• Max. battery charge/discharge efficiency 98.5% / 97.5%



INTERFACE:

• AC connection Terminal block
• Photovoltaic input MC4
• Backup line connection Terminal block
• Phoenix battery
• LCD screen
• Communication mode (monitoring system) Wi-Fi - LAN
• Communication ports (internal and with battery): Dongle (USB port for Wi-Fi/Ethernet module) - BMS (RJ45 port for battery communication) - Meter/CT (RJ45 port TA communication) - CAN (RJ45 port for parallel function) - COM/LCD (RJ45 port for external communication)



GENERAL INFORMATION:

• Parallel composition: Up to 10 inverters in the on-grid configuration, even of different models forming part of the X3S line. Only 3 CTs (included) are always required, to be connected to the master inverter
• Transformerless topology
• Standby consumption < 5 W
• Operating temperature range -35°C to +60°C (derating from +45°C)
• Cooling method Natural convection
• Ambient humidity 0 to 100% without condensation
• Storage temperature From -40°C to +70°C
• Altitude Up to 3000 m
• Noise <35 dB
• Overvoltage category II (DC input), III (AC output)
• Degree of protection IP65
• Mounting Wall mounting bracket
• Dimensions (H x W x D) 503 x 503 x 199 mm
• Net weight 30 kg
• 10-year warranty.
