Philips JM 35W Electronic Ballast HIDCPV35NS
PHL HIDCPV35NS
8727900859621
Philips HID-PV C 35 /S CDM electronic power supply/reactor, with the following characteristics:
- Input voltage: 220/240V
- Input frequency: 50 to 60 Hz
- Operating frequency (Rated) 0.14 kHz
- 100% power factor of load (Rated) 0.95
- Peak turn-on voltage (Max) 4.0 kV
- Ignition turn-off time (Rated): 18 minutes
- Line voltage performance (AC): -10%- +6%
- Line voltage safety: (AC)-18%-+10%
- Inrush current width: 0.25 ms
- Constant wattage deviation: -3%/+3%
- Power losses (Rated): 4.5W
Philips JM 35W Electronic Ballast HIDCPV35NS
€81.68
€81.68
Tax included
Tax included
Pay in installments with Klarna
Items Available: 17
High-quality, compact and lightweight product for optimal and reliable performance of 35W CDM-lamps.
Other technical features:
- Peak inrush current (Max): 26A
- Not suitable for outdoor environments
- Efficiency at max. load 84.7 %
- Reciprocal output cable capacity (Nom): 100 pF
- Cable length from device to lamp: 1.5 m
- Ballast contact cable cross section0.50-2.50 mm²
- Connector type: Insert
- Specified ballast power: lamp 35W
- Ambient temperature: 20/+55 °C
- Storage temperature: -25/+80 °C
- Enclosure temperature to define durability (Nom) 80 °C
- Maximum enclosure temperature (Max) 80 °C
- Weight: 0.216 kg
There are no reviews
Data sheet
- Type:
- Electronic ballasts
