Features:



Input parameters (DC):

• Maximum recommended PV power (per STC module) 37500W
• Maximum DC voltage 1100V
• Activation voltage (V start) 250V
• Rated voltage 600V
• MPPT voltage range 200V-1000V
• Number of MPP trackers 3
• Strings for MPP 2 trackers
• Max. input current for MPPT 26A
• Max dc current for MPPT 32A



Output parameters (AC):

• Nominal AC output power 25000W
• Max AC apparent power 27700VA
• Nominal AC voltage (range) 220V/380V, 230V/400V (340-440V)
• AC mains frequency (range) 50/60 Hz (45-55Hz/55-65 Hz)
• Maximum output current 40.0A
• Configurable power factor 0.8 in advance...0.8 in retardation
• Total harmonic distortion THDI <3%
• AC connection 3W+N+PE




Conversion efficiency:

• Maximum Efficiency 98.8%
• Euro Efficiency 98.5%
• MPPT Efficiency 99.9%



Safety features:

• DC reverse polarity protection
• DC disconnect switch
• AC/DC overvoltage protection Type II / Type II
• Insulation resistance monitoring
• AC short-circuit protection
• Ground fault detection device
• Network monitoring
• Anti-islading protection
• Device monitor. leakage current on all poles
• String monitoring
• AFCI protection



General data:

• Dimensions (W / H / D) in mm 580/435/230mm
• Weight 29.5 kg
• Operating temperature range 25°C ... +60°C
• Power consumption: night mode < 1W
• Topology Transformerless
• Cooling system controlled ventilation
• Environmental protection rating IP66
• Relative humidity 0~100%
• Altitude 4000 meters
• DC H4/MC4 connection (Optional)
• AC Connection Cable Grommet + Eyelet Terminals
• OLED+LED display/WIFI+APP
• Warranty: 10 years




Certifications:

• CE, VDE0126, Greece, EN50549, C10/C11, UTE C 15-712, IEC62116,IEC61727, IEC 60068, IEC 61683, CEI0-21, CEI0-16, N4105, TOR Erzeuger, G98/G99, G100, AS/NZS 3100, AS4777, UNE217001, UNE206007, PO12.2, KSC8565.
