The Yukon LPG detector is calibrated to detect a gas concentration of 10% of the L.I.E.(Lower Explosive Limit), this threshold may vary according to environmental conditions but will not exceed during the first 5 years of operation 15% of the L.I.E.. After that period or if the FAULT LED lights up, the Sensor Module will have to be replaced.




The functionality of the control unit is given by the fact that by detecting a possible leakage of Gas it warns, by means of Acoustic Buzzer and the lighting of the LEDs , that we are in a dangerous situation thus activating the internal relay to control the solenoid valve and intercept the Gas. Should we be away from home, however, the device will send a real-time notification directly to our smartphone through the appropriate App, thus keeping us updated on the security status of our home.




Standard specifications:

• Power supply: 100/230Vac - 50/60 Hz and 12Vdc
• Power consumption: 5.75VA max. at 230Vac - 2.5W max. at 12Vdc
• Alarm threshold: 10% LEL - Measuring range: 0/20% LEL
• Sensor: catalytic
• Alarm: optical (red led), audible (internal buzzer 85dBA at 1m), notifications on smartphone
• Relay: 10A @ 250Vac - 10A @ 30Vdc, SPDT
• Wireless protocol: IEEE 802.11 b/g/n, frequency: 2.4-2.4835 GHz
• Compliance with standard: EN 50194-1:2010




The Yukon LPG detector is calibrated to detect a gas concentration of 10% of the L.I.E.(Lower Explosive Limit), this threshold may vary according to environmental conditions but will not exceed, during the first 5 years of operation, 15% of the L.I.E.. After that period or if the FAULT LED lights up, the Sensor Module will have to be replaced. The functionality of the control unit is given by the fact that by detecting a possible leakage of Gas it warns, by means of Acoustic Buzzer and the lighting of the LEDs, that we are in a dangerous situation thus activating the internal relay to control the solenoid valve and intercept the Gas. In case, however, we are away from home, the device will send a real-time notification directly to our smartphone through the appropriate App, thus, we will always be updated on the security status of our home. The device should be installed on the wall at a distance of 30cm from the ceiling and at a distance of 1 to 4 meters from the gas user.
