Vortice Centrifugal Vacuum cleaner MICRO 100 11936


VOR 0000011936 8010300119366

Air and odor aspirator Vortice model MICRO 100 centrifugal duct, White color, Rated diameter 100 mm.

Request info about this product

Vortice Centrifugal Vacuum cleaner MICRO 100 11936

€119.65
€119.65

Vortice Centrifugal Vacuum cleaner MICRO 100 11936

€119.65
Tax included
klarna Pay in installments with Klarna
qty

Vortice Centrifugal Vacuum cleaner MICRO 100 11936

€119.65

Buy it within and receive it from Thursday, 20 June
Two-year warranty
Secure Payment
Easy return within 14 days

Features:

  • White ABS plastic resin construction
  • 2-speed induction type motor with starting capacitor, coupled to a forward vane centrifugal impeller
  • Equipped with thermo-fuse protection and self-lubricating bushings
  • Rated diameter 100 mm
  • Minimum flow rate: 65 m3/h
  • Maximum flow rate: 90 m3/h
  • Safety and performance certified IMQ and IMQ PERFORMANCE
  • Speed controllable by Vortex regulator.



Technical specifications:

  • Max. current consumption at max. speed (A) 0.13
  • Max. current consumption at min. speed (A) 0,10
  • Rated Duct Diameter (mm) 100
  • Frequency (Hz) 50
  • IP X4 Degree of Protection
  • Insulation Class II
  • Ø Exhaust (mm) 92.5/97
  • Weight (Kg) 1,80
  • Max. power consumption at max speed (W) 28
  • Max. power consumption at min speed (W) 20
  • Max. ambient temp. continuous operation (°C) 50
  • Voltage (V) 220-240
  • Free field sound emission [dB(A)] 3m 32.3
  • Max. flow rate at max. speed (m³/h) 90
  • Max. flow rate at min. speed (l/s) 18
  • Max. flow rate at min. speed (m³/h) 65
  • Max pressure at max speed (mmH2O) 22
  • Max pressure at max speed (Pa) 216
  • Max. pressure at min. speed (Pa) 157
  • Sound pressure Lp [dB (A)] 3m - max vel 39.2
  • Sound pressure Lp [dB (A)] 3m - min vel 32.3

Data sheet

Diameter:
100
Type:
Centrifugal fans
