Vortice Automatic Axial fan with Timer 120 11331
VOR 0000011331
8010300113319
Vortice Axial fan model M 120/5" AT (Automatic with Timer) from Wall with electrically opening and closing fins and adjustable TIMER 3-20 minutes, White colour, Rated diameter 120 mm.
Vortice Automatic Axial fan with Timer 120 11331
€143.44
€143.44
Tax included
Tax included
Pay in installments with Klarna
Items Available: 14
Frequently bought together
Features:
- UV resistant plastic resin construction resistant to ageing due to sun exposure ("UV resistant")
- Rated diameter 120 mm
- Thermally protected motor with shaft on self-lubricating bushings supports, combined with a helical impeller in thermoplastic material with wing profile blades
- Maximum flow rate 175 m3/h
- Equipped with electronic timer for the automatic shutdown of the product after a preset time that can be set, during installation, in the interval 3'-20' (default setting 3').
- Equipped with automatic opening and closing system of the front grille flaps
- Safety and performance certified IMQ and IMQ PERFORMANCE.
Technical specifications:
- Automatic Wing Opening
- Current consumption max (A) 0.12
- Rated Duct Diameter (mm) 120
- Frequency (Hz) 50
- IP X4 Degree of Protection
- Insulation 2nd class
- Ø Exhaust (mm) 119
- Weight (Kg) 0.8
- Power consumption max (W) 20
- Max. ambient temp. continuous operation (°C) 50
- Voltage (V) 220-240
- Max. flow rate (l/s) 48.6
- Max flow rate (m³/h) 175
- Max pressure (mmH2O) 4.5
- Max pressure (Pa) 44
- Sound Pressure Lp [dB (A)] 3m 39.5
- RPM 2100
Very good! Require a non stop power!
Ok grazie mille ☺️ okay grazie mille 🤩 ok
Prodotto conforme alla richiesta, tutto ok.
Ottimo acquisto. Risponde alle mie richieste. Consegna rapida. Prodotto giunto in perfette condizioni. Lo consiglio.
Non lo usato ancora ma sembra tutto ok.
Data sheet
- Diameter:
- 120
- Type:
- Axial fans
- Functions:
- Fins and Timer
