Abb Modular Contactor ESB20 20A 2NA 24 Vac 1 Module ESB2020N01


ABB ESB2020N01 3471523004962

Abb ESB20 modular contactor with the following characteristics:

  • Rated control circuit voltage: 24 V
  • Rated operating current: 20 amps
  • Impulse withstand voltage: 6 kV
  • Rated insulation voltage: 400 V
  • Number of poles: 2
  • Number of modules: 1
  • Number of NO main contacts: 2
Request info about this product

Abb Modular Contactor ESB20 20A 2NA 24 Vac 1 Module ESB2020N01

€39.91
€39.91

Abb Modular Contactor ESB20 20A 2NA 24 Vac 1 Module ESB2020N01

€39.91
Tax included
klarna Pay in installments with Klarna
qty

Abb Modular Contactor ESB20 20A 2NA 24 Vac 1 Module ESB2020N01

€39.91

Buy it within and receive it from Tuesday, 28 May
Two-year warranty
Secure Payment
Easy return within 14 days

The ESB20..N installation contactors are used to control single loads up to 20 A and can be operated in alternating or direct current. These contactors are made for use in domestic applications and industrial environments.

Buzz-free operation, low power consumption, and built-in overvoltage protection. Various combinations of contacts and accessories are available.

A contactor is a device for closing and opening electrical circuits, mostly high voltage circuits, by remote control.

IEC 17-3 defines a contactor (contactor) as a device capable of interrupting or establishing current within a circuit. To do this, the device opens and closes contact channels between the system and the power structure. In short, a kind of switch to be used for all eventualities.

Features:

  • Rated operating voltage: 220 V DC Main Circuit - 250 V AC Main Circuit.
  • DC Main Circuit
  • Tightening torque: Control Circuit 0.9 Nm - Main Circuit 1.2 Nm
  • Wire stripping length: Control Circuit 7 mm - Main Circuit 10 mm
  • Degree of protection: IP20
  • Pollution degree: 3
  • Ambient temperature: In operation -25/+55 °C - In storage -40/+80 °C
  • Product width: 18 mm
  • Product height: 85 mm
  • Product depth: 65 mm
  • Product net weight: 140 grams

Data sheet

Type:
Contactors
Voltage:
24VAC
Modules:
1
Poles:
2P
Degree of protection:
IP20
Amps:
20A
