Abb Contactor 25A 2NA+2NC 24V DC-AC ESB2522N01
ABB ESB2522N01
4013614523946
Abb Contactor ESB25-22N-01:
- Rated operating current AC-1 25A
- 2NA+2NC contacts
- Rated control circuit voltage 24V DC-AC
- Rated operating voltage: 220V DC main circuit - 400V AC main circuit
€45.98
Items Available: 2
The ESB25..N installation contactors are used to control single-phase and three-phase loads up to 25 A and can be operated on alternating or direct current.
These contactors are made for use in both domestic applications and industrial environments. The following advantages are provided:
- Hum-free operation, low power consumption
- Integrated power consumption and surge protection
- Various combinations of contacts and accessories are available
Features:
- Net product width: 36 millimeters
- Net height of product: 85 millimeters
- Net product depth/length: 65 millimeters
- Product net weight: 0.245 kg
- Rated frequency (f): 400 Hz control circuit - 50 Hz control circuit - 60 Hz control circuit - DC control circuit - 50 Hz main circuit - 60 Hz main circuit - DC main circuit
- Rated operating current AC-1 (I e ): (NC) 25 A - (NON) 25 A
- Rated operating current AC-3 (I e ): (230 V) single-phase, NC 6 A - (230 V) single-phase, NO 9 A
- Rated operating power AC-1 (P e ): (230 V) Single-phase, NC 5.8 kW - (230 V) Single-phase, NO 5.8 kW
- Rated operating power AC-3 (P e ): (230 V) Single-phase, NC 1.3 kW - (230 V) Single-phase, NO 1.3 kW
- Rated operating current AC-7a (I e ): (NC) 25 A - (NO) 25 A
- Rated operating power AC-7a (P e ): (230 V) Single-phase, NC 5.8 kW - (230 V) Single-phase, NO 5.8 kW
- Rated operating current AC-7b (I e ): (230 V) Single-phase, NC 6 A - (230 V) Single-phase, NO 9 A
- Rated operating power AC-7b (P e ): (230 V) Single-phase, NC 0.9 ??kW - (230 V) Single-phase, NO 1.3 kW
- Recommended screwdriver: Pozidriv 1 control circuit - Pozidriv 1 main circuit
- Rated impulse withstand voltage (U imp ): 6 kV
- Rated insulation voltage (U i ): 500 volts
- Main circuit connection capacity: Flexible with ferrule 1x 1.5 ... 10 mm² - Flexible with ferrule 2x 1.5 ... 2.5 mm² - Flexible with insulated ferrule 1x 1.5 ... 10 mm² - Flexible with insulated ferrule 2x 1.5 mm² - Flexible with insulated ferrule 1x 1.5 ... 10 mm² - Flexible 2x 1.5 ... 4 mm² - Rigid 1x 1.5 ... 10 mm² - Rigid 2x 1.5 ... 4 mm²
- Capacity control circuit connection: Flexible with ferrule 1x 1 ... 2.5 mm² - Flexible with ferrule 2x 0.75 ... 1 mm² - Flexible with insulated ferrule 1x 1 ... 2.5 mm² - Flexible with insulated ferrule 2x 0.75 ... 1 mm² - Flexible hose 1x 1 ... 4.0 mm² - Flexible 2x 1 ... 2.5 mm² - Rigid 1x 1 ... 4 mm² - Rigid 2x 1 ... 2.5 mm²
- Tightening torque: Control circuit 0.9 N-m - Main circuit 1 N-m
- Wire stripping length: Control circuit 7 mm - Main circuit 10 mm
- Degree of protection: IP20
- Number of Poles: 4
- Number of NC Main Contacts: 2
- Number of NO main contacts: 2
- Width in number of modular spacings: 2.0
- Pollution degree: 3
There are no reviews
Data sheet
- Type: Contactors
- Voltage: 24V
- Modules: 2
- Poles: 4P
- Amps: 25A
