Siemens Simatic S7-1500 AI 8XU/I/RTD/TC ST Analog Input Module 6ES75317KF000AB0
SIE 6ES75317KF000AB0
4025515079514
Analog Input Module Siemens Simatic S7-1500 AI 8XU/I/RTD/TC ST 16 bit resolution, 0.3 % accuracy, 8 channels in groups of 8, 4 channels for RTD measurement, 10V common mode voltage; diagnostics; process interrupts; scope of delivery incl. power supply element, screen bracket and screen clamp: front connector (screw terminals or push-in terminals) to be ordered separately.
€843.85
Items Available: 22
: 1
Features:
- Product type designation AI 8 x U/I/RTD/TC ST
- Hardware version FS04
- Firmware version V2.0.0
- FW upgrade possible Yes
- Product function I&M data Yes; I&M0 ... I&M3
- Engineering with STEP 7 TIA Portal design/integrated from version V12 / V12 - STEP 7 design/integrated from version V5.5 SP3 / - PROFIBUS from version GSD/revision GSD V1.0 / V5.1 PROFINET from version GSD/revision GSD V2.3 / -
- Oversampling operating mode No - MSI Yes
- CiR - Configuration in RUN Reparameterization in RUN possible Yes - Calibration in RUN possible Yes
- Supply voltage Nominal value (DC) 24 V - Permissible range, lower limit (DC) 19.2 V - Permissible range, upper limit (DC) 28.8 V - Reverse polarity protection Yes
- Current consumption, max. 240 mA; with DC 24 V power supply
- Dimensions Width 35 mm - Height 147 mm - Depth 129 mm
- Weight 310 g.
There are no reviews
Data sheet
- Type: Analog Input Modules
- Voltage: 24V
