For small and medium-sized businesses, Easy UPS 1 Ph On-Line, provides essential power protection for unstable power conditions, ensuring constant and reliable connectivity at the most critical times.




Other technical features:

• Input voltage limits: 110...300V half load, 176...300V full load
• Mains frequency: 40...70 Hz automatic detection
• Output frequency (sync to mains): 50/60 Hz +/- 3 Hz sync to mains
• Topology: Double conversion online
• Waveform type: sinusoidal output
• Efficiency 94 % (full load)
• Additional information: configurable for 220:230 or 240 V rated output voltage
• Internal bypass type (automatic and manual)
• Crest factor 3:1
• Operating ambient temperature: 0/+40°C
• Relative humidity: 0...95 % without condensation
• Operating altitude: 0 to 3000 m
• Storage temperature: -15/+60°C
• Reference standards: EN/IEC 62040-1, EN/IEC 62040-2
• Storage relative humidity: 0...95 % Non-condensing
• Storage altitude: 0 to 15000 m
• Noise level: 58 dBA
• Degree of protection IP20
• Battery type: lead-acid battery
• Battery voltage: 192V
• Preinstalled batteries 0
• Empty battery compartments 0
• Typical charging time: 3 hours
• Battery life: 3/5 years
• Battery charging power (watts): 531W
• Audible alarm: alarm with battery operation, distinct low battery alarm, continuous tone alarm in case of overcharge
• Control panel: multi-function lcd control and status console
• Free slots: 1
• Emergency Power Off (EPO): yes
• Surge protection and filtering: rated surge energy (Joule) 600 J
