4Power Uninterruptible Power Supply UPS Third Power CAB3000 3kVA THPMMCAB03K10T
4PW THPMMCAB03K10T
The UPS 4Power Third Power CAB3000 (THPMMCAB03K10T) 3kVA on-line double conversion protects servers and critical loads with regenerated sine wave, PFC ?0.99 and advanced functions (ABM, hot swap, SNMP).
-
3000VA / 2700W (inverter cos 0.9) single-phase/single-phase
-
On-Line double conversion technology VFI-SS-II2: zero transfer time
-
Input PFC with cos 0.99 and IGBT rectifier
-
Regenerated sinusoidal output with THD <3%
-
VRLA AGM batteries 72Vdc 9Ah, autonomy 7/10 (80%/50% load)
-
RS232/USB communication, SNMP slot, LCD display and automatic bypass
€955.26
Items Available: 1
UPS 4Power Third Power CAB3000: true continuity and protection for sensitive loads
The UPS 4Power Third Power CAB3000 THPMMCAB03K10T is designed to ensure stable and filtered power supply in environments where network disturbances are not tolerable. The On-Line double conversion technology keeps the load always powered by the inverter: this means zero intervention time in case of blackout and effective isolation from micro-interruptions, voltage drops, overvoltages, and electrical disturbances. It is the correct choice when the goal is to protect IT infrastructures, medical devices, or light industrial users that require constant energy quality.
PFC and IGBT rectifier: cleaner network and greater efficiency
The THIRD Power CAB series integrates an input stage with IGBT rectifier and PFC (Power Factor Correction). In practice, the UPS absorbs current more efficiently, reducing harmonic impact and bringing the input power factor to 0.99 values. This helps improve the behavior of the electrical system and reduce waste, especially in contexts with multiple electronic devices and switching power supplies.
Power 3000VA / 2700W: suitable for servers, LAN, and professional users
With 3000VA nominal power and 2700W active power, the UPS is sized to power multiple devices simultaneously: servers, storage, network switches, telecommunications equipment, professional PCs, and critical loads in small industrial environments. The inverter with cos 0.9 ensures good available useful power, making the UPS a balanced choice between performance and sizing.
VRLA AGM 72Vdc batteries: advanced autonomy and management
The VRLA AGM battery equipment (voltage 72Vdc, capacity 9Ah) offers continuity suitable for typical controlled shutdown or temporary service maintenance needs: 7 minutes at 80% load and 10 minutes at 50% load. The recharge time is 6-8 hours. Advanced functions such as A.B.M. (intelligent battery management), battery test, A.C.B. warning, and the possibility of Hot Swap Battery (hot replacement) are designed to reduce maintenance and increase reliability over time.
| GENERAL DATA | |
|---|---|
| Model | THIRD POWER CAB. 3000 |
| Product code | THPMMCAB03K10T |
| Nominal power | 3000 VA |
| Active power | 2700 W |
| INPUT | |
| Input voltage | 208 V, 220 V, 230 V, 240 V (1Ph + N) selectable |
| Input voltage range | 110 ÷ 300 Vac |
| Nominal frequency | 40 ÷ 70 Hz (autosensing) |
| Accepted frequency variation | ±5 Hz |
| Input power factor | ≥ 0.99 with THD < 2% |
| OUTPUT | |
| Nominal voltage | 208 V, 220 V, 230 V, 240 V (1Ph + N) selectable |
| Voltage stability | ±1% |
| Nominal frequency | 50 / 60 Hz ±0.1% (battery mode) |
| Waveform | Sine wave |
| Harmonic distortion (THD) | ≤ 2% with linear load |
| Crest factor | 3:1 |
| AC/AC efficiency | > 95% |
| Intervention time | Zero – On-line double conversion |
| Overload (25 °C) | <150% Pn for 30 s / >150% Pn for 1 s |
| BATTERIES | |
| Battery type | VRLA AGM |
| Battery voltage | 72 Vdc |
| Capacity | 9 Ah |
| Recharge time | 6 ÷ 8 h |
| Autonomy (80% / 50% load) | 7 min / 10 min |
| GENERAL INFORMATION | |
| Dimensions (W × D × H) | 190 × 452 × 341 mm |
| Weight | 26.6 kg |
| Telephone / LAN protection | RJ45 filter (10BaseT) |
| Communication | RS232 / USB |
| Safety / EMC compliance | EMC Dir. 2004/108/E: EN 62040-2:2006, EN 61000-6-1-3:2007 LVD Dir. 2006/95/EC: EN 62040-1:2008, EN 62040-3:2002 |
| Marks | CE |
| Operating temperature | 0 ÷ 40 °C (relative humidity up to 90%) |
| Operating altitude | Up to 3500 m (<95% RH, non-condensing) |
Management and integration: LCD, RS232/USB and SNMP The interactive LCD display facilitates local parameter control, while RS232/USB communication and the SNMP slot (for optional card) allow remote monitoring, supervision, and automatic shutdown procedures via dedicated software. The equipment is completed by the automatic bypass and the provision for an external manual bypass, useful for operational continuity and maintenance.
There are no reviews
Data sheet
- Type: Uninterruptible Power Supply UPS
- Rated Power: 3000VA
- Active Power: 2700W
- Endurance: 10 minutes
