4Power Uninterruptible Power Supply UPS Third Power Plus 5000 5KVA THPPMM500010T
4PW THPPMM500010T
The UPS 4Power Third Power Plus 5000 (THPPMM500010T) 5kVA/5kW On-Line double conversion with PFC and inverter cos? 1 ensures total continuity, pure sine wave, and advanced management for IT, LAN, and critical loads.
-
5000VA / 5000W with inverter cos = 1 (maximum useful power)
-
On-Line double conversion technology VFI-SS-II2: zero intervention time
-
Input PFC with IGBT rectifier (input cos 0.99)
-
VRLA AGM batteries (192/240 Vdc, 7Ah) with 68 h recharge
-
Typical autonomy 10/15 (80%/50% load), expandable up to 3 hours with external battery packs
-
Management and control: LCD, RS232/USB, SNMP slot, automatic bypass, and provision for manual bypass.
€1,778.76
Items Available: 2
: 1
UPS 4Power Third Power Plus 5000: advanced protection and total isolation from the network
The UPS 4Power Third Power Plus 5000 THPPMM500010T is designed to ensure continuous and superior quality power supply in environments where electrical stability is crucial. The double conversion On-Line technology keeps the load always powered by the inverter, eliminating micro-instructions and typical network disturbances (spikes, voltage dips, fluctuations). The concrete advantage is a zero intervention time and real isolation: servers, network equipment, and sensitive devices operate with regenerated, filtered, and stabilized voltage.
5kVA/5kW with cos 1: more useful power for real loads
One of the strengths of the Third Power Plus series is the inverter with cos = 1: in practice, the nominal power 5000VA coincides with the active power 5000W. This makes the UPS particularly suitable for modern loads with switching power supplies and significant power demands, as it utilizes all available capacity without losing useful Watts. It is the ideal choice for server rooms, rack cabinets, LAN infrastructures, laboratories, and small industrial users where continuity cannot be delegated to line-interactive solutions.
PFC and IGBT rectifier: efficiency and quality also on the input side
The IGBT rectifier with PFC (Power Factor Correction) improves the UPS's behavior towards the network, reducing the reset harmonic content (THDi) and bringing the input power factor to values of 0.99. This results in cleaner absorption and more efficient energy management, with both technical benefits (less stress on the system) and economic benefits (better overall efficiency).
VRLA AGM batteries and modular autonomy: tailored continuity
The UPS uses VRLA AGM batteries with voltage 192/240 Vdc and capacity 7Ah, with a recharge time of 6-8 hours. In standard configuration, it offers an indicative autonomy of 10 minutes at 80% load and 15 minutes at 50% load, useful for overcoming short blackouts or allowing controlled shutdown. If the project requires longer coverage, expansion with external battery packs up to 3 hours is foreseen (depending on load and configuration), making the solution suitable even for sites with unstable networks.
Professional functions: ABM, Hot Swap, EPO, and remote monitoring
To maximize reliability and maintenance, you will find functions such as A.B.M. (intelligent battery management), battery test, A.C.B. warning, Cold Start, Auto Restart, and Hot Swap Battery (hot replacement). The presence of automatic bypass and provision for external manual bypass facilitates interventions and maintenance without stopping the service. With RS232/USB port, SNMP slot, and interactive LCD display, the UPS easily integrates into IT environments and supervision systems, with shutdown software included.
| GENERAL DATA | |
|---|---|
| Model | THPP5000 |
| Product code | THPPMM500010T |
| Nominal power | 5000 VA |
| Active power | 5000 W |
| INPUT | |
| Input voltage | 208 V, 220 V, 230 V, 240 V (1Ph + N) selectable |
| Input voltage range | 110 ÷ 300 Vac |
| Nominal frequency | 40 ÷ 70 Hz (autosensing) |
| Accepted frequency variation | ±5 Hz |
| Input power factor | ≥ 0.99 with THD < 2% |
| OUTPUT | |
| Nominal voltage | 208 V, 220 V, 230 V, 240 V (1Ph + N) selectable |
| Voltage stability | ±1% |
| Nominal frequency | 50 / 60 Hz ±0.1% (battery mode) |
| Waveform | Sine wave |
| Harmonic distortion (THD) | ≤ 2% with linear load |
| Crest factor | 3:1 |
| AC/AC efficiency | > 95% |
| Intervention time | Zero – On-line double conversion |
| Overload (25 °C) | <150% Pn for 30 s / >150% Pn for 1 s |
| BATTERIES | |
| Battery type | VRLA AGM |
| Battery voltage | 192 / 240 Vdc |
| Capacity | 7 Ah |
| Recharge time | 6 ÷ 8 h |
| Autonomy (80% / 50% load) | 10 min / 15 min |
| GENERAL INFORMATION | |
| Dimensions (W × D × H) | 191 × 465 × 711 mm |
| Weight | 52.0 kg |
| Telephone / LAN protection | RJ45 filter (10BaseT) |
| Communication | RS232 / USB |
| Safety / EMC compliance | EMC Dir. 2004/108/E: EN 62040-2:2006, EN 61000-6-1-3:2007 LVD Dir. 2006/95/EC: EN 62040-1:2008, EN 62040-3:2002 |
| Marks | CE |
| Operating temperature | 0 ÷ 40 °C (relative humidity up to 90%) |
| Operating altitude | Up to 3500 m (<95% RH, non-condensing) |
There are no reviews
Data sheet
- Type: Uninterruptible Power Supply UPS
- Rated Power: 5000VA
- Active Power: 5000W
- Endurance: 10 minutes
15 minutes
