Special features:

• Shockproof and anti-UV plastic resin structure
• Nominal diameter: 100 mm
• Ceramic type heat exchanger with hexagonal cells. High heat exchange efficiency (up to 90% at minimum air flow rate)
• High-efficiency EC fan motor; five operating speeds to maximize performance when needed or minimize noise and consumption
• Controls for on/off, operating mode adjustment and fan speed selection, located on the machine.



Three different operating modes:

• Continuous ventilation with heat recovery: the product cyclically extracts and injects air to and from the room by recovering the energy stored in the heat exchanger
• Air extraction-only ventilation: stale air is extracted from the room
• Air supply-only ventilation: the product introduces fresh air into the room
• Two air filters, an IsoCoarse 65% and a coarser pre-filter for dust, both easily removed for washing them
• Saturated filter indicator light visible at the bottom of the chassis, immediately behind the front cover
• Mechanical air supply quick shut-off system integrated into the product chassis
• External rubber grille, which can be installed from the outside using dowels or inserted from the inside, through the hole in the wall, without resorting to external scaffolding
• Anti-insect mesh, which can be inserted into the duct from inside the room
• Possibility of slaving to remote sensors C-TEMP and C-HCS for automatic management of operation logic




Features:

• ISOCoarse 65% filter class
• Max absorbed current (A) 0.04
• Nominal Duct Diameter (mm) 100
• Frequency (Hz) 50-60
• Insulation II° class
• Weight (Kg) 3.10
• Max. power consumption (W) 4
• Max. ambient temperature for continuous operation (°C) 30
• Voltage (V) 220-240
• Max recovery efficiency (%) 90
• Max flow rate at max speed (l/s) 10.5
• Max flow rate at max speed (m³/h) 38
• Max flow rate at min speed (l/s) 1.7
• Max flow rate at min speed (m³/h) 6
• Sound power Lw dB (A) - max vel 66.8
• Sound power Lw dB (A) - min vel 36.6
• Sound power Lw dB(A) - med vel 49.5
• Max pressure at max vel (mmH2O) 13.7
• Max pressure at max vel (Pa) 130
• Max pressure at min vel. (mmH2O) 1
• Max pressure at min vel. (Pa) 10
• Sound pressure Lp dB (A) 3m - max vel 49.2
• Sound pressure Lp dB (A) 3m - med vel 32.0
• Sound pressure Lp dB (A) 3m - min vel 19.1
