Overview:

• Gas water heaters in the Opalia F range are easy to operate and reliable. The Opalia F model is available in 12-, 15- or 17-liter sealed-chamber versions, all with electronic ignition
• A new burner makes it possible to minimize NOx emissions and achieve Class 6, as required by the ErP directive
• Modern design and extremely compact size (35cm): water heaters can be easily installed in any environment, even outdoors having IPX5D approval and the possibility of being protected down to -25°C with a special accessory
• Maximum safety: the safety thermostat intervenes in case of domestic hot water overtemperature; the ionization flame control stops gas supply in case of flame failure at the burner. Electronic control: it is possible to optimally adapt the operation of the appliance to the conditions of use and hot water temperature, ensuring maximum sanitary comfort and optimizing gas consumption



Advantages:

• Instant sanitary comfort
• Maximum efficiency
• Easy installation in any room
• Intuitive touch display
• Extremely small dimensions
• Low NOx emissions (class 6)



User interface with digital display:

• The user interface of the Opalia F Low NOx water heater range combines aesthetics and ease of use, allowing the user to intuitively understand the management of the appliance and adjust it according to their needs
• Ability to access parameters
• Hot water temperature adjustment
• Water temperature display on digital display
• Simple and intuitive management



Features:

• Capacity at the firebox kW 23.3
• Minimum flow rate l/min 2.5
• DHW temperature min/max °C 38 / 6o
• Supply pressure mbar 20
• Flue outlet mm 80/80 - 80/125 - 60/100
• Electrical protection IPX 5D
• Sound power dB 57
• Weight 17.5 Kg
• Type GAS II2HM3+
