Advantages:

• 4 MP CMOS image sensor, 1/3, low illuminance, high image definition
• Outputs max. 4 MP (2688 × 1520) at 30 fps
• H.265 codec, high compression rate, low bit rate
• Built-in IR LED, max. IR distance: 40 m
• ROI, SMART H.264+/H.265+, exible encoding, applicable to various bandwidths and storage environments
• Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermark, applicable to various monitoring scenes
• Intelligent detection: intrusion, tripwire (supports classical and Accurate detection functions of vehicles and people)
• Anomaly detection: motion detection, video tampering, scene - Outputs max. 4 MP (2688 × 1520) at 30 fps edit, SD card absent, SD card full, SD card error, network disconnection, Technical specification IP conflict, illegal access, voltage detection
• Supports max. 256 GB micro SD card
• 12V DC/POE power supply
• IP67 protection
• SMD Plus



SMD Plus:

• With an intelligent algorithm, Smart Motion Detection technology can classify the targets that trigger motion detection and filter the motion detection alarm triggered by unaffected targets to realize an effective and accurate alarm.



Intelligent H.265+ and Intelligent H.264+:

• With advanced scene-adaptive rate control algorithm, intelligent encoding technology realizes higher encoding efficiency than H.265 and H.264, provides high-quality video and reduces storage and transmission costs.



Perimeter protection:

• Using deep learning algorithm, the perimeter protection technology can accurately recognize people and vehicles. In restricted area (e.g., such as pedestrian area and vehicular area), the false alarms of intelligent detection based on target type (such as tripwire, intrusion, fast movement, parking detection detection, and gathering detection) are largely reduced.



Starlight:

• Starlight technology is mainly applied to low-light environments and can provide clear and colorful video. Even in the min. lighting environment, the technology can ensure the good image effect.



WDR:

• With advanced Wide Dynamic Range (WDR) technology, the Dahua network camera provides clear details in an environment with strong brightness contrast. The light area and dark area can achieve sharp video even in high brightness environment or backlight shadows.



Camera:

• 1/34 megapixel progressive CMOS image sensor
• Maximum Resolution 2688(O)×1520(V)
• Rom 128MB
• RAM 512MB
• Progressive Scanning System
• Electronic Shutter Speed Auto/Manual 1/3 s1/100000 s
• Minimum Illumination 0.005 Lux@F1.5
• S/N ratio > 56dB
• Illumination distance 40 m (131.23 ft)
• Illuminator on/off control Automatic/manual
• Number of illuminator 2 (IR LED)
• Pan/tilt/rotation range Pan: 0°355°; Tilt: 0°75°; Rotation: 0°355



Lens:

• Motorized Varifocal IP camera input
• Mounting type f14
• Focal length 2.7 mm13.5 mm
• Maximum Aperture F1.5
• Field of view Horizontal: 104°27° Vertical: 55° 15° Diagonal: 124° 31°
• Fixed iris type
• Close focusing distance 0.8 m (2.6 ft.)



Professional, Smart:

• Tripwire perimeter protection; intrusion (person and vehicle recognition)
• Smart Search Collaborates with Smart NVR to perform intelligent search, event extraction and merging into video



Video:

• H.265; H.264; H.264H; H.264B; MJPEG video compression (supported by secondary stream only)
• Intelligent Codec Intelligent H.265+/ Intelligent H.264+
• Video frame rate Main stream (2688 × 1520 at 125/30 fps) Secondary stream (704 × 576 at 125 fps/704 × 480 at 130 fps)
• Stream capacity 3 streams
• Resolution 4M (2688×1520); 3M (2304×1296); 1080p (1920×1080); 1.3 million (1280 × 960); 720p (1280×720); D1 (704×57480); CIF (352×288/352×240)
• CBR/VBR bit rate control
• Video bitrate H.264: 3 Kbps8192 Kbps H.265: 3 Kbps8192 Kbps
• Day Night Auto(ICR)/Color/B&W
• BLC
• HLC
• WDR 120dB
• White balance Auto/natural/roadlight/outdoor/manual/custom regional
• Get control Auto/manual
• 3D DNR Noise Reduction
• Motion detection OFF/ON (4 areas, rectangular)
• Region of interest (RoI) yes 4 areas
• Intelligent illumination
• Image rotation 0°/90°/180°/270° (Supports 90°/270° at 1920 × 1080 resolution and below.)
• Privacy masking 4 areas



Alarm:

• Alarm event No SD card; SD card full; SD card error; less SD card service time (access; voltage detection; security exception; motion detection; scene change;)



Network:

• RJ-45 (10/100 Base T)
• SDK and API
• Protocol IPv4;IPv6;HTTP;HTTPS;TCP;UDP;ARP;RTP;RTSP;RTCP; RTMP;SMTP;FTP;SFTP;DHCP;DNS;DDNS;QoS;UPnP;NTP; Multicast;ICMP;IGMP;NFS;PP
• Interoperability PoE;802.1x;SNMP ONVIF(Prole S/Prole G);CGI;P2P;Milestone;Genetec
• Scene Self-adaptive



Certifications:

• CE-LVD: EN62368-1
• CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
• FCC: 47 CFR FCC Part 15, Subpart B
• UL/CUL: UL60950-1 CAN/CSA C22.2 N.60950-1-07



General:

• 12 V DC/PoE (802.3af) power supply.
• Power consumption <8.5 W
• Operating conditions -30°C to +60°C (-22°F to +140°F)/minus 95%.
• Storage conditions -40°C to +60°C (-40°F to +140°F
• Degree of protection IP67 IK10
• Metal casing
• Dimensions 122 mm × 88.9 mm (ÿ4.8" × 3.5")
• Weight 492 grams (1.1 pounds)
