Dahua PoE Switch 8 ports 10/100 Mbps and 2 uplink ports 110W M-0032447
DAH M-0032447
6923172571168
Dahua CS4010-8ET-110 cloud-managed desktop switch, intelligent management, IEEE802.3bt standard support, metal frame, with the following features:
-
Number of ports: 8 PoE 10/100 Mbps + 2 uplink 10/100/1000 Mbps
-
PoE power supply: 110W
-
Management: cloud, web and app
-
Function: VLAN on port, Jumbo Frame, DHCP Client
-
Protection: ESD and surge protection
-
Structure: Metal
-
Mounting: Wall or Desktop
€96.33
Items Available: 11
Dahua PoE 8-port switch with smart management from cloud
Smart 10-port PoE switch designed to provide power and networking to devices such as IP cameras, Wi-Fi access points, VoIP phones, all manageable from the cloud, browser or mobile app. The 8 PoE ports support up to 90W (on port 1) according to the IEEE802.3bt standard, while the 2 Gigabit uplink ports provide fast connectivity to routers and NVRs.
High compatibility and advanced management
Supports major network protocols (IEEE802.3, .3u, .3x, .3ab) and includes on-port VLAN, intelligent PoE, flow control, DHCP client, with a switching capacity of 5.6 Gbps and 4.17 Mpps forwarding rate. Intuitive management interface enables quick remote configuration to monitor power consumption, active ports, and PoE power status.
Compact, robust design and versatile installation
With a durable and compact metal enclosure (only 30 mm high), this switch is ideal for desktop or wall-mounted installations in residential, commercial or industrial settings. It is designed to operate over a wide temperature range (-10°C / +55°C) and incorporates protection against electrostatic discharge and lightning, ensuring reliability even in critical environments.
Dahua PoE Switch Technical Specifications
Hardware
| Parameter | Value |
|---|---|
| Ethernet port | 8 |
| Ethernet port speed | 10/100 Mbps |
| Uplink speed | 10/100/1000 Mbps |
| Slot Description. | Port 1-8: 8 × RJ-45 10/100 Mbps (PoE); Port 9-10: 2 × RJ-45 10/100/1000 Mbps (uplink) |
| Reset button | 1 |
| Power supply | 54 VDC, 2.22 A (external power supply) |
| Power Consumption. | Min: ≤3 W; Max: 110 W |
| Operating temperature | -10 °C TO +55 °C |
| Operating humidity | 5%-95% (RH), non-condensing |
| Storage temperature | -40 °C ÷ +70 °C |
| Storage humidity | 5%-95% (RH), non-condensing |
Performance
| Parameter | Value |
|---|---|
| Layer | Layer 2 |
| Management type | Web/App (Smart/Forks) |
| MTBF | 150 years |
| Switching capacity | 5.6 Gbps |
| Packet forwarding speed | 4.17 Mpps |
| Buffer size | 4 Mbit |
| Jumbo Frame | 9216 bytes |
| MAC table | 8K entries |
| VLAN number | 32 |
| Communication standards | IEEE802.3; .3u; .3x; .3ab |
PoE characteristics
| Parameter | Value |
|---|---|
| PoE standards supported | IEEE802.3af, .3at, .3bt, Hi-PoE |
| PoE Power | Port 1: ≤ 90 W, Ports 2-8: ≤ 30 W, Total: ≤ 110 W |
| PoE Management | Automatic |
| Pin Assignment | 1,2,4,5 (V+); 3,6,7,8 (V-) |
| Long distance PoE transmission | Supported |
| VLAN Function | Port-based |
| Flow Control | IEEE 802.3x |
| DHCP | DHCP client |
General
| Parameter | Value |
|---|---|
| ESD Protection | Air discharge: 8 kV; contact: 6 kV |
| Lightning protection | Common mode: 4 kV; differential: 2 kV |
| Net / gross weight | 0.5 kg / 1.25 kg |
| Product dimensions. | 190 × 106 × 30 mm |
| Material | Sheet metal |
| Installation | Desktop or wall-mounted |
| Certifications | CE |
There are no reviews
Data sheet
- Type: PoE Network Switches
- System: IP
- Doors: 8+2
