Came motor for sliding gates BKS22TGS up to 2200KG 801MS-0130
CMC 801MS-0130
8050456071217
Came motor for sliding gates BKS22TGS:
- Max leaf weight 2200KG
- Max leaf length 23 meters
- Power supply 230 400 V AC three-phase.
Control panel with self-diagnosis of safety devices (002ZT6) to be purchased separately.
Came motor for sliding gates BKS22TGS up to 2200KG 801MS-0130
€712.75
€712.75
Tax included
Tax included
Pay in installments with Klarna
Items Available: 5
Features:
- Self-diagnosis of safety devices
- Predisposition for installation of magnetic limit switches
- Configurable safety inputs for direct management of resistive sensitive edges (8k2?)
- IP44 degree of protection
- Power supply (V - 50/60 Hz) 230 400 V AC THREE-PHASE
- Motor power supply (V) 230 400 V AC THREE-PHASE
- Absorption (A) 1,5
- Power 520W
- Maneuvering speed (m/min) 10,5
- Cycles/hour 14
- Thrust (N) 1650
- Working temperature (°C) -20 ÷ +55
- Motor thermal protection (°C) 150.
There are no reviews
Data sheet
- Type:
- Engines Gates
- Model:
- Sliding gate
