Siemens Simatic S7-1500 DI 16x24V DC HF Digital Input Module 6ES75211BH000AB0

Siemens
Siemens
SIE 6ES75211BH000AB0 4025515080138

Siemens Simatic S7-1500 DI HF digital input module 6ES75211BH000AB0 with the following features:

  • Number of inputs: 16, divided into groups of 16, with 2 inputs that can be used for counting

  • Rated value: 24 V DC

  • Power dissipation: 2.6W

  • Counting amplitude: Up to 32 bits, ideal for precise signal monitoring

  • Input delay: Adjustable between 0.05 and 20 ms, to suit the specific needs of the application

  • Dimensions: 35x147x129 mm (W-H-P)

Designed to offer efficient management of digital inputs within automation systems. Features built-in diagnostics and advanced functions such as process interrupt, making it ideal for complex applications in industrial settings.

Do you have questions about this product or did you not find what you were looking for? Ask us!
Siemens Simatic S7-1500 DI 16x24V DC HF Digital Input Module 6ES75211BH000AB0
€279.14
€279.14

€279.14
Tax included
Calculate shipping cost
Items Available: 22
Further availability of the manufacturer
€279.14

Buy it within and receive it from Monday, 26 January
Two-year warranty
Easy return within 14 days
Purchase with tax breaks

Are you a professional ?

Request access to

Trustpilot

SIMATIC S7-1500 Digital Input Module: Precision and Versatility

The SIMATIC S7-1500 DI 16xDC 24V HF Digital Input Module offers an excellent solution for controlling and monitoring signals within automation systems. With its 16 digital input channels, this module can handle a wide variety of signals, with two inputs specifically designed for counting. Adjustable input delay from 0.05 to 20 ms allows the module to be adapted to different operational needs, ensuring fast and accurate response. In addition, reverse polarity protection ensures the safety of the module, preventing possible damage during installation and operation.

Diagnostics and Reliability of the S7-1500 DI 16xDC 24V HF Input Module

The SIMATIC S7-1500 series DI 16xDC 24V HF digital input module has advanced diagnostic features that greatly enhance its reliability. With built-in diagnostics, the status of the inputs can be monitored in real time, detecting any anomalies or malfunctions and thus ensuring system continuity of operation. The process interrupt offers the ability to react immediately to changes in input status, making the module ideal for critical applications that require immediate response.

Features:

  • Allowable range: Lower limit 19.2 V, upper limit 28.8 V

  • Reverse polarity protection

  • Current consumption, max.: 20 mA (with DC 24 V supply)

  • Power draw from backplane bus: 1.1 W

  • Power dissipation, typical: 2.6 W

  • Number of inputs: 16 (with two inputs that can be used for counting)

  • Input delay time: Adjustable between 0.05 ms and 20 ms

  • Cable length: With shielding max. 1,000 m, without shielding max. 600 m

  • Connectable transducers: 2-wire sensor

  • Allowable quiescent current (2-wire sensor), max.: 1.5 mA

  • Filtering and processing time (TWE), min: 80 µs (with filtering time of 50 µs)

  • Bus cycle time (TDP), min.: 250 µs

  • Insulation: Tested at 707 V DC (Type Test)

  • Operating ambient temperature: - Horizontal mounting position: -30/+60°C - Vertical mounting position: -30/+40°C

  • Maximum installation altitude: 5,000 m above sea level (Limitations for altitudes above 2,000 m)

  • Dimensions: Width 35 mm, Height 147 mm, Depth 129 mm

There are no reviews

Data sheet

Type:
Digital Input Modules
Voltage:
24V
