Strengths:

HD input:

• S+265/H.265/H.264 video formats
• Connectable to third-party network cameras
• Input of up to 40 channels
• Supports real-time display, storage and playback of a connected camera with up to 12MP resolution



HD output:

• Simultaneous HDMI and VGA outputs
• HDMI video output with resolution up to 4K (3840 × 2160)



HD storage:

• 2 SATA interfaces, up to 10TB per HDD
• S+265 compression



HD transmission:

• 2 self-adaptive RJ45 10/100 Mbps network interfaces



Various applications:

• Centralized management of IP cameras, including configuration, information import/export, real-time information display, updating, etc.
• Ability to connect to intelligent IP cameras and record, playback and backup VCA alarms
• VCA detection alarm supported
• Intelligent search of selected area in video and intelligent playback to improve playback efficiency
• Web6 supports plug-in-free browsing and can preview videos on all browsers
• Supports cloud update



Features:

Input:

• 40-channel video input
• Max. resolution 12MP
• Two-way audio input 1 ch., 3.5mm
• Bandwidth Input 320Mbps; Output 320Mbps



Output:

• HDMI/VGA output
• HDMI: 1 channel, 3840×2160, 2560×1600, 2560×1440, 1920×1080, 1280×720, 800×600, 1024×768,1366×768, 1440×900, 1280×800
• VGA: 1 channel, 1920×1080, 1280×720, 800×600, 1024×768, 1366×768, 1440×900, 1280×800
• 1/3/4/6/8/9/10/13/16/20/25/36/40/64 screen division
• Audio Output 1xRCA



Decoding:

• S+265/H.265/H.264 Decoding Format
• Recording Resolution 12MP/8MP/6MP/5MP/4MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF
• Preview capabilities 3x12MP, 4x8MP, 4x6MP, 5x5MP, 8x4MP, 9x3MP, 16x1080P, 32x720P, 40x4CIF
• Synchronous playback 3x12MP, 4x8MP, 4x6MP, 5x5MP, 8x4MP, 9x3MP, 16x1080P, 16x720P
• Record encryption Yes



Hard Disk:

• SATA 2 interfaces for 2 HDDs
• Capacity Up to 10TB for each HDD



External Interface:

• Network interface 2 self-adaptive RJ45 10/100/1000 Mbps network interfaces.
• USB interface 1xUSB 2.0, 1x USB 3.0
• Serial interface 1xRS-485, 1x RS-232
• In/Out alarms 16/4



Network:

• TCP/IP protocol, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, IGMP, QoS, IPV4, IPV6, Multicast, ARP, UDP, SNMP, SSL, Telnet, RTMP, NFS
• ONVIF system compatibility (S/T/G PROFILE), SDK, P2P



General data:

• Web version Web6
• Language Simplified Chinese, Traditional Chinese, English, Spanish, Korean, Italian, Turkish, Russian, Thai, French, Polish, Dutch, Hebrew, Arabic Operating conditions -10°C/+55°C, 10% 90% RH
• Power supply 100~240VCA, 50~60 Hz
• Power consumption (without HDD) ? 25W (without HDD)
• 1U chassis
• Dimensions 47.5×277×440mm
• Weight (without HDD) 2.3Kg
