Features:

• Video inputs 16 PoE (4K, 5MP, 3MP, Full-HD, HD, D1)
• Main video outputs 1 (VGA - 1920x1080@60Hz), 1 (HDMI - 4K@30Hz)
• Audio inputs/outputs 1 (RCA) / 1 (RCA) (G.711u / G.711a)
• Alarm inputs/outputs 8/4
• Video compression H.264, H.265
• Frame rate in playback/recording 30fps@8MP
• Provided hard disk capacity 2TB (8TB max)
• Additional hard disks (SATA) 3 (3x8TB max)
• Embedded Linux operating system
• Recording methods Automatic, manual, scheduled, event
• Recording type Dual streaming
• Maximum no. of live channels viewable simultaneously 16
• Maximum no. of channels played back simultaneously 1@4K, 4@FULL-HD
• Supported protocols DDNS, Comelit DNS, DHCP, HTTP, HTTPS, NTP, PPPoE, SMTP, TCP/IP, UPnP, ONVIF, IEEE 802.1x
• Manual IP Assignment, DHCP
• HTTPS, SSL, RSA+AES encrypted transmission
• Max. bandwidth (Mbps) 160
• Remote control by browser Internet Explorer, Firefox, Chrome, Safari
• Remote control from Comelit CCTV Manager software
• Remote control from mobile APP Comelit CCTV
• Simultaneously connected users 5
• Main functions Video analysis (only with dedicated cameras), Parking management function, Alarm system function
• Type of connections/ports 1 x Ethernet 10/100/1000 Mbit/s, 1xUSB 2.0, 1xUSB 3.0, 1xRS485, 16xEthernet 10/100 Mbit/s PoE (IEEE 802.3af, 150W max)
• Maximum Power Consumption (W) 16
• Maximum power consumption per POE port (W) 13
• Maximum distance in long range mode (m) 180
• Supply voltage (VAC) 100÷240, 50÷60Hz
• Height (mm) 70 Width (mm) 440 Depth (mm) 390
• Product weight (g) 4600
• Type coating materials Metallic
• Product color Black
• Operating temperature (°C) -10 to 50
• Operating humidity (RH max) (%) 25 ÷ 90
• Included accessories Power supply unit, Mouse, Rack mounting brackets
• USB 2.0 System Backup



Functions:

• Motion detection (zones) 396
• Anti-tampering Yes
• Privacy zones (No.) 4
• Video signal loss Yes
• System log Yes
• E-mail notification Yes
• Pre-event recording 5 seconds
