LEF LED strip power supply unit 50W 12VDC constant voltage IP20 LE5012TF
LEF LE5012TF
8054521535222
Power supply for LEF constant voltage (CV) dimmable Phase Cut LED strips with the following characteristics:
- Input voltage: 220-240Vac
- Output voltage: 12 Vdc
- Output power (Min and Max): 12-50W
- Output current (Min and Max): 1000-4160 mA
- Control: TRIAC-IGBT
- Mains frequency: 50/60 Hz
- Degree of protection: IP20
- Dimmable
Power supply not suitable for no-load operation.
€34.82
Items Available: 2
: 1
Features:
- Plastic container
- Power supply unit for independent use
- Electrical protection class II
- Degree of protection IP20
- Energy Efficiency: 85%.
- Open circuit protection (OCP)
- Overload protection (OLP)
- Overtemperature protection (OTP)
- Short circuit protection (SCP)
- Power Factor Factor (PFC) 0.95
- Ambient operating temperature Ta -20°C ÷ +50°C
- Maximum temperature at point Tc 75°C
There are no reviews
Data sheet
- Type: Power supplies
- Degree of protection: IP20
- Watts: 41 to 50W
- Output voltage: 12 Vdc
- Input voltage: 220/240V
