LEF LED Strip Power Supply 50W 24VDC Dimmable Phase Cut IP20 LE5024TF

Lef
Lef
LEF LE5024TF 8054521530500

Power supply for LEF constant voltage (CV) dimmable Phase Cut LED strips with the following characteristics:

  • Input voltage: 220-240Vac
  • Constant output voltage: 24Vdc
  • Output power (min and max): 12-50W
  • Output current (min and max): 500-2080mA
  • Control: TRIAC-IGBT
  • Mains frequency: 50/60 Hz
  • Degree of protection: IP20

Power supply not suitable for no-load operation.

  • dimmable
    • Do you have questions about this product or did you not find what you were looking for? Ask us!
    LEF LED Strip Power Supply 50W 24VDC Dimmable Phase Cut IP20 LE5024TF
    €34.82
    €34.82

    €34.82
    Tax included
    Calculate shipping cost
    Items Available: 3
    Further availability of the manufacturer
    €34.82

    Buy it within and receive it from Tuesday, 23 December
    Two-year warranty
    Easy return within 14 days
    Purchase with tax breaks

    Are you a professional ?

    Request access to

    Trustpilot

    Features:

    • Plastic container
    • Power supply unit for independent use
    • Electrical protection class II
    • Degree of protection IP20
    • Dimmable at Phase Cut with modes: TRIAC Leading -Edge, IGBT Trailing-Edge
    • Energy efficiency: 85%.
    • Open Circuit Protection (OCP)
    • Over-Temperature Protection (OTP)
    • Overload protection (OLP)
    • Short circuit protection (SCP)
    • Power factor factor (PFC) 0.95
    • Ambient operating temperature -20°C to +50°C
    • Maximum temperature at Tc point 75°C

    There are no reviews

    Data sheet

    Type:
    Power supplies
    Degree of protection:
    IP20
    Watts:
    41 to 50W
    Output voltage:
    24 Vdc
    Input voltage:
    220/240V
    Consulta scheda EPREL info_outline
