Abb release coil 12-110V AC DC S3CA1L
ABB S3CA1L
4053546116700
ABB S3CA1L release coil enables remote opening of devices by electrical control, compatible with MCB S200 and S300 series switches.
-
Remote control for opening MCB devices
-
Rated voltage from 12 to 110V AC/DC
-
Installation on the left side of the devices
-
Screw terminal with 0.8 Nm tightening torque
-
Broad compatibility with ABB S200 and S300 series
-
Complies with UL 1077 and CSA 22.2 No. 235 standards
€31.04
Items Available: 3
: 1
Abb S3CA1L release coil: reliable remote control for circuit breakers
The ABB S3CA1L release coil is designed to provide safe and efficient remote opening of ABB S200 and S300 series circuit breakers. This auxiliary module is an ideal solution for electrical systems that require automatic or remote circuit interruption in case of emergency, maintenance or centralized control.
Wide operating voltage range
Thanks to its wide voltage rating range, from 12 to 110 V alternating current (AC) or direct current (DC), the ABB S3CA1L throw coil easily adapts to different system configurations, making it extremely versatile for both industrial and civil environments.
Easy installation and extended compatibility
The device is designed for mounting on the left side of circuit breakers, with connection via screw terminals that ensure a secure and stable connection. It is compatible with a wide range of ABB circuit breakers, including S200, S200 M, S200 MT, S200 MTR, S200 P, S200 MUC, S300 P, VY30 and SD200, thus offering great flexibility when designing and maintaining installations.
Guaranteed strength and safety
The launch coil complies with international standards UL 1077 and CSA 22.2 No. 235, ensuring reliable performance and safe operation. Its compact (85x17.4x74.1 mm) and lightweight (only 63 grams) body allows quick installation without compromising available space in the electrical panel. In addition, it is operational in a wide temperature range of -25 to +55 °C, making it suitable even in critical environments.
| Feature | Value |
|---|---|
| Product code | S3CA1L |
| Type | Launch coil for remote control |
| Rated voltage | 12...110 V AC/DC |
| Input voltage type | AC/DC |
| Installation | Left side switch |
| Clamp type | Screw type |
| Tightening torque | 0.8 N-m |
| Dimensions (H × W × D) | 85 × 17.4 × 74.1 mm |
| Weight | 0.063 kg |
| Operating temperature | -25 °C TO +55 °C |
| Standards | UL 1077, CSA 22.2 No. 235 |
| Compatibility | S200, S200 M, S200 MT, S200 MTR, S200 P, S200 MUC, S300 P, VY30, SD200 |
| Connection capacity. | Flexible: 0.75...2.5 mm² Rigid: 0.75...2.5 mm² Stranded: 0.75...2.5 mm² |
| Cable stripping length | 7 mm |
There are no reviews
Data sheet
- Type: Coils
- Voltage: 12/110V
- Model: Release
