Power Supply for mast amplifiers FTE 12V 350 mA 1 IN 1 OUT LPS301
FTE LPS301
8436023597531
Switching Power Supply FTE for mast amplifiers, compact and highly efficient, with the following features:
-
Output voltage: 12V DC
-
Maximum deliverable current: 350 mA
-
Input voltage: 230 Vac
-
Number of inputs/outputs: 1 IN - 1 OUT
-
Operating frequency (passband): 5 - 862 MHz
-
Type of power supply: Switching
-
Mounting: On DIN rail or flush-mounted box 503
€11.20
Items Available: 9
: 9
Frequently bought together
Switching Power Supply FTE for mast amplifiers
The mast power supply FTE belonging to the LPS series is a compact and efficient device, designed to remotely power mast amplifiers, active antennas, and preamplifiers via coaxial cable. Thanks to switching technology, it ensures high voltage stability, automatic short circuit protection, and low energy consumption, making it ideal for professional and residential installations.
Universal compatibility with the FTE range
Perfectly compatible with amplifier series:
-
LG
-
AMP
-
AMK
-
MX20 / MX30 / MK36
It can also be used with other 12V devices within the 350 mA absorption limit.
Simple and safe installation
The flame-retardant ABS enclosure and compact design allow installation in:
-
Standard flush-mounted boxes 503
-
DIN rail in electrical panels
The system ensures maximum safety thanks to class II insulation and automatic autorestart protection in case of a short circuit, avoiding the risk of permanent damage to the system.
Optimal performance across the entire TV band
The device offers low pass-through attenuation (< 0.5 dB) over a wide frequency range (5 ÷ 862 MHz), ensuring excellent TV signal quality and minimizing losses.
Technical Features FTE Power Supply
| Technology | High efficiency switching |
| Output voltage | 12 V DC |
| Maximum deliverable current | 350 mA |
| Input voltage | 230 V AC |
| Network frequency | 50 Hz |
| Number of inputs / outputs | 1 IN / 1 OUT |
| Passband | 5 ÷ 862 MHz |
| Pass-through attenuation | < 0.5 dB |
| Insulation class | II |
| Short circuit protection | Self-resetting |
| Mounting | On DIN rail or flush-mounted box 503 |
| Enclosure | Flame-retardant ABS plastic |
| Operating temperature | -10 ÷ +40°C |
| Dimensions (W × H × D) | 61 × 38 × 52 mm |
| Signal protection | Low attenuation to maintain quality |
| Additional features | Compact, flame-retardant enclosure with short circuit protection |
consigliato buona..................................
Funciona bien cumple con su cometido buen producto
Ottimo, e veloce nella spedizione. Prodotto come da articolo online
Data sheet
- Type: Power supplies
- Version: 350 MA
