Electromechanical Room Thermostat Fantini Cosmi IP40 C10A2

Fantini Cosmi
Fantini Cosmi
FAN C10A2 8025863026679

Electromechanical room thermostat Fantini Cosmi with tinned copper spiral capillary. Ideal for greenhouses, cold rooms, electrical panels, and industrial environments, with the following features:

  • Type of regulation: Electromechanical liquid expansion

  • Protection degree: IP40

  • Nominal insulation voltage: 380V

  • Nominal continuous service current: 15A

  • Sensitive element: Stainless steel membrane

  • Capillary: Tinned copper spiral

  • Installation: Wall-mounted

Do you have questions about this product or did you not find what you were looking for? Ask us!
Electromechanical Room Thermostat Fantini Cosmi IP40 C10A2
€49.94
€49.94

€49.94
Tax included
Calculate shipping cost
Items Available: 65
Further availability of the manufacturer
€49.94

Buy it within and receive it from Tuesday, 3 February
Two-year warranty
Easy return within 14 days
Purchase with tax breaks

Are you a professional ?

Request access to

Trustpilot

Robust and precise room thermostat for professional environments

The Fantini Cosmi C10A2 is an electromechanical thermostat with a spiral capillary, designed for temperature regulation in technical and industrial environments such as cold rooms, greenhouses, warehouses, curing plants, and industrial electrical panels. Thanks to liquid expansion operation, it ensures stable and precise ambient temperature regulation.

Spiral capillary: sensitivity and versatility

The heart of the thermostat is a tinned copper spiral capillary, which allows sensitive and immediate detection of temperature variations. The stainless steel membrane sensitive element ensures corrosion resistance and long-lasting durability, even in harsh conditions.

Quick snap switch with gold-plated contacts

The thermostat is equipped with a quick snap changeover micro switch, with gold-plated AgCdO contacts, ensuring greater reliability and a long operational life even under high electrical loads. The capacity is 15(6)A at 250V~ 50Hz according to EN 60730-1 and up to 15A with Ui 380V~ according to EN 60947-5-1.

Resistant materials and safe installation

The body structure, made of shockproof and self-extinguishing V0 thermoplastic, makes the thermostat resistant to shocks, heat, and flames. Installation is wall-mounted, with connection output via PVC cable gland (optionally replaceable with shockproof thermoplastic G1/2 cable gland, accessory code 303298LA).

There are no reviews

Data sheet

Type:
Thermostats
Model:
Without display
WIFI:
No
