Bticino MatixGo Electronic Room Thermostat Grey JG4441
BTI JG4441
8005543725740
Bticino MatixGo electronic room thermostat grey colour JG4441 Intelligent control for heating and cooling.
-
Complete climate control: Integrated heating and cooling functions.
-
Reliable relay output: 1 switching contact, 8 A - 250 Vac (cos = 1) / 2 A - 250 Vac (cos = 0.6)
-
Standard power supply: 230 Vac, frequency 50/60 Hz
-
Compatible with MatixGo series: Mounting to J4702, J4702G, J4703, J4704, J4707 holders
-
Compliant standard: EN 60730-1, 2-9, with rated impulse voltage 4 kV
-
Compact design: Only 2 modules for convenient and unobtrusive installation
€62.14
Items Available: 42
: 2
Frequently bought together
Bticino MatixGo Electronic Thermostat
The Bticino MatixGo JG/W4441 Electronic Thermostat is the ideal solution for precise and safe regulation of heating and cooling systems. Designed to provide reliable control of room temperature, this device makes it easy to set the desired mode, ensuring optimal comfort in every season.
With a relay output with 1 switching contact, the thermostat supports loads up to 8 A under ideal conditions, ensuring compatibility with most home heating systems and small cooling systems. Dual operation mode allows alternating heating and cooling without the need for additional devices.
Features and benefits
Precise temperature control: Electronic control ensures accurate room temperature control, reducing energy waste and improving overall comfort. Simple and modular installation: The thermostat occupies only 2 modules, allowing quick and neat installation on Bticino MatixGo series holders (J4702, J4702G, J4703, J4704, J4707), ideal for both new installations and replacements. Safety and Regulatory Compliance: Compliant with EN 60730-1, 2-9 and with a rated impulse voltage of 4 kV, the device ensures reliability and safety in daily operations.
General Technical Specifications.
| Feature | Value |
|---|---|
| Rated voltage | 230 Vac |
| Frequency | 50 to 60 Hz |
| Rated current | 2 A |
| Differential current (Idn) | 2 A |
| Contact type | 1 switching contact |
| Maximum load | 8 A - 250 Vac (μ cos φ = 1) 2 A - 250 Vac (μ cos φ = 0.6) |
| Number of modules | 2 |
| Series | MatixGo |
| Mounting | On frames J4702, J4702G, J4703, J4704, J4707 |
| Standard | EN 60730-1, 2-9 |
| Rated impulse voltage | 4 kV |
Electrical Connection
| Characteristic | Value |
|---|---|
| Clamp type | Screw type |
| Clamp capacity | 2 × 2.5 mm² |
| Stripping length | 6 mm |
| Cable compatibility | Flexible and rigid |
Mechanical and Environmental Characteristics
| Feature | Value |
|---|---|
| IP rating | IP40 (with plate and frame) |
| Degree of protection IK | IK04 |
| Housing | PC |
| Cover | ABS |
| Knob | PA6 |
| Material Properties | Halogen Free, UV Resistant |
| Self-extinguishing | 850°C/30s (active parts) 650°C/30s (passive parts) |
| Operating Temperature | -5°C ÷ +35°C |
| Storage Temperature | -10 °C ÷ +70 °C |
There are no reviews
Data sheet
- Type: Thermostats
- Model: Without display
- Installation: Recessed
- WIFI: No
