Voltage measuring instrument Vemer 2 DIN 600VAC VM260700
VEM VM260700
8007951067542
Vemer multifunction voltage measuring instrument, with the following features:
- 2 DIN modules
- DIN rail mounting
- Can be configured as a voltmeter or ammeter for true rms (TRMS) measurement of alternating voltages and currents in single-phase systems
- With red LED display, which allows good readability of the measurement displayed even at a distance
- Power supply 230 Vac
- Frequency 50/60Hz
- Absorption 4 VA
- Display: 3 red 7.6 mm digits
- Visualization of numbers on the display max 999
- Degree of protection IP20/51 (on front)
- Counter 3 digits
€62.37
Items Available: 8
Features:
- Vemer Series
- 2 DIN modules
- DIN rail mounting
- Can be configured as a voltmeter or ammeter for true rms (TRMS) measurement of alternating voltages and currents in single-phase systems
- With red LED display, which allows good readability of the measurement displayed even at a distance
- Power supply 230 Vac
- Frequency 50/60Hz
- Absorption 4 VA
- Display: 3 red 7.6 mm digits
- Visualization of numbers on the display max 999
- Degree of protection IP20/51 (on the front)
- Operating temperature -10°C +45°C
- Storage temperature -20°C +70°C
- Humidity 10+90% non-condensing
- Capacity 600 V / x/5 A (on current transformer)
- Counter 3 digits
Data sheet
- Type: Voltage detectors
