Lovato Backup Power Supply for PMVF Interface Protectors PMVFUPS02
LOV PMVFUPS02
8013975324882
The Lovato PMVFUPS02 backup power supply is designed to ensure continuity of power supply to AC-powered PMVF interface protectors. Equipped with full static technology, it ensures reliable and uninterrupted operation thanks to the accumulable energy of 645 Ws and a power rating of 650 VA:
- Full static technology: uninterrupted power supply
- Input and output: 230 VAC, single-phase
- Storable energy: 645 Ws for 60 seconds of runtime
- Power: 650 VA for each output
- Compatibility: perfect for PMVF interface protections
- Mounting: DIN rail EN 50022, IP20, 9-module execution
€491.25
Items Available: 11
Frequently bought together
Lovato Backup Power Supply for PMVF Interface Protections PMVFUPS02
The PMVFUPS02 power supply ensures uninterrupted operation of PMVF interface protections in the event of a power outage. With a compact and reliable design, it provides a stable 230 VAC output, ideal for industrial and professional installations. Its full-static technology eliminates any interruption in power supply, ensuring that connected devices remain operational under all conditions.
High performance with storable energy and autonomy
With accumulable energy of 645 Ws and a power rating of 650 VA, the Lovato PMVFUPS02 can keep connected devices powered for up to 60 seconds. This autonomy is sufficient to prevent disruption or damage to sensitive equipment during short power interruptions or transitions.
Advanced technical specifications for reliable applications
The backup power supply supports a wide input voltage range (100-260 VAC) and an operating frequency from 40 to 65 Hz, making it compatible with various power grid conditions. With 5A (5x20 mm) fuse protection and a rugged IP20-rated design, it is ideal for controlled industrial environments. The -5°C to +55°C operating temperature ensures reliable performance even in changing environmental conditions.
Compact design and easy installation
The Lovato PMVFUPS02 is designed to be DIN EN 50022 rail mounted, occupying only 9 modules. Fixed connections with screw terminals support conductors up to 2.5 mm² in cross section, simplifying installation. Its compact dimensions (157.5 x 90 x 70 mm) and weight of only 430 grams make it a versatile device that is easy to integrate into electrical panels.
Detailed technical specifications
- Input/output voltage: 230 VAC
- System type: single-phase
- Storable energy: 645 Ws (60-second runtime)
- Power rating: 650 VA
- Operating voltage range: 100-260 VAC
- Operating frequency: 40-65 Hz
- Input/output protection: 5A fuse (5x20 mm)
- Connections: Fixed terminals (min 0.2 mm² / max 2.5 mm², max tightening torque 0.5 Nm)
- Mounting: DIN rail EN 50022
- Degree of protection: IP20
- Operating temperature: -5°C to +55°C
- Dimensions: 157.5 x 90 x 70 mm
- Weight: 430 grams
There are no reviews
Data sheet
- Type: Power supplies
- Voltage: 230V
