Chint lithium battery for photovoltaic inverter 5.0 CPS ESSR-05KL1
67B 1.0106.1703
The Chint CPS ESSR-05KL1 lithium battery is the ideal choice for those seeking a reliable and innovative residential energy storage solution. With a capacity of 5.0 kWh, it offers high performance, flexibility and security for photovoltaic energy systems. With its easy installation and robust design with IP65 protection, this battery is perfect for a variety of home and residential environments:
-
High capacity: 5.0 kWh storage for optimal energy management
-
Installation flexibility: modular design for easy expansion and storage optimization
-
Advanced safety: compliance with VDE 2510-50 and IEC 63056 standards
-
Ease of use: automatic BMS address assignment to reduce installation time
-
Weather resistance: IP65 rating for safe installation in various environments.
To be combined for operation the CPS ECD51 Power Control Module part number 1.0106.1704
At most, the system can be extended up to 4 batteries.
€1,504.38
Items Available: 32
: 16
Frequently bought together
Advantages of the Chint CPS ESSR-05KL1 Battery
Flexibility and modularity
With its modular design, this battery easily adapts to changing energy needs. The standardization of components optimizes installation time and simplifies inventory management, making it an ideal choice for both new installations and retrofits.
Certified safety
The Chint CPS ESSR-05KL1 battery provides superior safety. With IP65 protection, it is dust and moisture resistant, allowing installation even in outdoor environments. It is certified to VDE 2510-50 and IEC 63056 standards, ensuring long life and protection against failure.
Easy installation
Reduce installation time and costs with BMS automatic address assignment technology, which eliminates complex manual configurations. The system is designed for quick setup, even in existing PV systems.
Applications
- Residential storage systems
- Retrofit of existing photovoltaic systems
- Indoor and outdoor environments due to IP65 protection
Features of the Photovoltaic Battery System
System Parameters
| Feature | Detail |
|---|---|
| Power control module | CPS ECD51 |
| Battery extension module | CPS EBM016100LF-L |
| Rated voltage (V) | 51,2 |
| Operating voltage range (V) | 44,8 ~ 57,6 |
| Maximum charge/discharge current (A) | 50 |
| Maximum power (kW) | 2,5 |
| Nominal charge/discharge energy (kWh) | 5,12 |
| Usable battery energy (kWh) | 5,12 |
| DOD | 100% |
| Weight (kg) | 60 |
| Dimension (W x D x H, mm) | 670 x 178 x 650 |
| Maximum storage expandability (kWh) | Up to 61.44 kWh |
| Operating temperature (?) | Charge: 0 ~ 50 Discharge: -10 ~ 50 |
| Operating humidity | 5 ~ 95% |
| Protection | IP65 |
| EOL | 70% |
| Connection | CAN |
| Certificates | IEC 62619, IEC 63056, IEC 62040-1, VDE 2510-50, CE EMC, UKCA, UN 38.3 |
| Installation | Floor mounting and wall mounting |
| Cooling method | Natural |
| Altitude | 3000 |
Battery Extension Module
| Feature | Detail |
|---|---|
| Module | CPS EBM016100LF-L |
| Nominal charge/discharge energy (kWh) | 5,12 |
| Dimension (W x D x H, mm) | 670 x 178 x 370 |
| Weight (kg) | 44 |
| EOL (%) | 70 |
Power Control Module
| Feature | Detail |
|---|---|
| Model | CPS ECD51 |
| Operating voltage range (V) | 44,8 ~ 57,6 |
| Maximum charge/discharge current (A) | 120 |
| Dimension (W x D x H, mm) | 670 x 178 x 280 |
| Weight (kg) | 8 |
