Gewiss mobile socket 3P+E 32A IP44 red 380V GW62019H
GEW GW62019H
8011564798342
Gewiss straight HP mobile outlet, with the following features:
- Rated voltage: 200-250V
- Frequency: 50/60 Hz
- Rated current 32A
- Poles: 3P+T
- Degree of protection IP44/IP54
- Wiring: screw
Gewiss mobile socket 3P+E 32A IP44 red 380V GW62019H
€12.70
€12.70
Tax included
Tax included
Pay in installments with Klarna
Items Available: 191
Features:
- Gewiss Series
- Red color
- Shock resistance IK09
- Reference h: 6
- Terminal clamping capacity: 2.5-6 mm² flexible cables - 2.5-10 mm² rigid cables
- Clamping capacity: 9.2-19.9 mm
- Temperature range -25 +55 °C
- Wiring type: screw
- Material Type: Halogen free according to EN 60754-2
- Electrocod code: 2231
- Glow wire test: 850 °C (active parts) - 650 °C (passive parts)
- Total number of operations: >2000
- Interrupting capacity at 1,1 Un: 40A
- Insulation resistance: > 10 MΩ
- Allowable overload: 42 A
- Thermopressure with ball: 125 °C (Active Parts) - 80 °C (Passive Parts)
There are no reviews
Data sheet
- Type:
- Sockets CEE
- Voltage:
- 380/415VAC
- Poles:
- 3P+T
- Degree of protection:
- IP44
- Installation:
- Furniture
- Amps:
- 32A
